Side View - NEONODE zForce AIR Touch Sensor User Manual

zForce AIR® Touch Sensor User's Guide
Product number
0° 90°
NNAMC2590PC01 NNAMC2591PC01
NNAMC2660PC01 NNAMC2661PC01
NNAMC2740PC01 NNAMC2741PC01
NNAMC2810PC01 NNAMC2811PC01
NNAMC2880PC01 NNAMC2881PC01
NNAMC2950PC01 NNAMC2951PC01
NNAMC3020PC01 NNAMC3021PC01
NNAMC3100PC01 NNAMC3101PC01
NNAMC3170PC01 NNAMC3171PC01
NNAMC3240PC01 NNAMC3241PC01
NNAMC3310PC01 NNAMC3311PC01
NNAMC3380PC01 NNAMC3381PC01
NNAMC3460PC01 NNAMC3461PC01

Side View

These measurements are identical for all sensor lenghts but varies some between the 0° and 90 ° types. The
position of origin is marked with "zero software".
https://support.neonode.com
Measurements (mm)
A B C
259.2 208.5 263.2
266.4 208.5 271.9
273.6 208.5 277.6
280.8 208.5 286.3
288 208.5 292
295.2 208.5 300.7
302.4 208.5 306.4
309.6 208.5 315.1
316.8 208.5 320.8
324 208.5 329.5
331.2 208.5 335.2
338.4 208.5 343.9
345.6 208.5 349.6
D
2
3.5
2
3.5
2
3.5
2
3.5
2
3.5
2
3.5
2
