zForce AIR® Touch Sensor User's Guide
Name Description
orientation Orientation
confidence Confidence
pressure Pressure
Location and size coordinates can be specified with up to 3 bytes. The byte order in decreasing significance - big-
endian. For example:
• 1 byte: location x = loc-x-byte1
• 2 bytes: location x = (loc-x-byte1 << 8) + loc-x-byte2
• 3 bytes: location x = (loc-x-byte1 << 16) + (loc-x-byte2 << 8) + loc-x-byte3
Location is signed, and size is not.
The location coordinate scale is one of two systems, depending on which detector is used:
• Physical: Robair Air and Core detectors: The unit is 0.1 mm. A coordinate value of 463 thus means 46.3 mm
from origin.
• Relative: Triangles and Shape Air detectors: Fraction of the largest screen dimension as fixed point with 14
bits after the radix point (q14). On a widescreen display, the horizontal axis ranges [0, 2
14
2 * 9/16[ ([0, 16383], [0,

The zForce AIR Touch Sensor uses Robair, thus the unit is 0.1 mm.
Size is in mm.
Confidence and pressure is fraction of full in percent.
Enable Execution
This command will activate the touch sensor, and notifications of detections will start streaming.Enable
request command
enable {
enable 0
}
command response
enable {
reset NULL
}

This is actually incorrect response. It should respond enable.
https://support.neonode.com
Comment
Hand orientation
9215]).
Software Integration
14
[, and vertical [0,
65
