TECHNICAL DATA

Nominal voltage

Power consumption ( max. )
Protection degree
Cable length

Recommended Pressure Range

Ambient Temperature Range
Water Temperature Range
Product Weight
Product Dimension ( L × B × H )
Maximum Load (Seat and Lid)
Max. flow rate Rear Wash
Max. flow rate Front Wash
Spray arm position
Water temperature
Air dryer temperature
Seat temperature
TECHNICAL SUPPORT
For any questions or any assistance with this product, please contact your dealer or call us at
1-800-769-4857
support@axentproducts.com
www.axentbath.us
LEGAL DIRECTIONS
This manual contains important information on the intended use, correct operation and proper maintenance of the equipment. Knowledge of and
compliance with the instructions of this manual are provided for both the safe use of the equipment and for the safety of its operation and main-
tenance. In this manual, not all kinds of applications and improper manipulations are considered. In addition, attention is drawn to the following:
The content of these instructions is neither part of any previous or existing agreement, commitment or legal relationship, nor does it change from
an existing agreement, commitment or legal relationship. Any commitment by AXENT results from the respective warranty. These include the
complete and authoritative warranty obligation AXENT. The statements in this manual do not constitute an extension or a restriction of the claims
under the warranty provisions. This manual is protected by copyright. Copies and / or translations into other languages may be made only with
prior written approval of AXENT.
120 V~, 60 Hz
1300 W
IPX4
1. 1 m ( 43 inches )
0.27 - 0.55 MPa ( 40 - 80 psi )
4 - 40 °C ( +39 to +104 °F )
4 - 35 °C ( +39 to +95 °F )
48 kg ( 106 lbs )
725 × 403 × 490 mm ( 32 × 19
150 kg ( 330 lbs )
650 ml/min ( gal/min )
650 ml/min ( gal/min )
31 - 39 °C ( +88 to +102 °F )
30 - 46 °C ( +86 to +115 °F )
29 - 37 °C ( +84 to +98 °F )
× 19 inches )
5 levels
5 levels
5 levels
5 levels
5 levels
5 levels
35
