Multifunctional Wheelchair
Phoenix PU
Seat with hygiene opening
Art. No.:
350.xx.10/150 kg
(330.69 lbs)
Serial Number
06/2005 (Th.B.)
Image shows: Phoenix PS
Important suggestions!
Read this user manual
Keep this user manual at hand for future use and resale.
The user instructions and the maintenance manual are downloadable on our homepage.
User Manual
before first use
of the chair and keep it at hand for the user.
REBOTEC
®
Rehabilitationsmittel GmbH
DE-49610 Quakenbrück, Artlandstr. 57-59
Telephone: +49(0)5431/9416-0
Telefax: +49(0) 5431/9416-66
http://www.rebotec.de
E-mail: info@rebotec.de
Phoenix PS
Seat without hygiene opening
Art. No.:
350.xx.40/150 kg
(330.69 lbs)
Serial Number
06/2005 (Th.B.)
xx = colour code

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phoenix PU and is the answer not in the manual?

Questions and answers

Summary of Contents for Rebotec Phoenix PU

  • Page 1 DE-49610 Quakenbrück, Artlandstr. 57-59 Telephone: +49(0)5431/9416-0 Telefax: +49(0) 5431/9416-66 BA No.: 02.07.135/2017-01 http://www.rebotec.de E-mail: info@rebotec.de User Manual Multifunctional Wheelchair Phoenix PU Phoenix PS Seat with hygiene opening Seat without hygiene opening Art. No.: 350.xx.10/150 kg Art. No.: 350.xx.40/150 kg (330.69 lbs) (330.69 lbs)
