Manual ModTable
Assembly Instructions
vs 5.0
Page
| ModTable | vs 4.11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Manual ModTable and is the answer not in the manual?

Questions and answers

Related Manuals for MultiTable Manual ModTable

Summary of Contents for MultiTable Manual ModTable

  • Page 1 Manual ModTable Assembly Instructions vs 5.0 Page | ModTable | vs 4.11...

  • Page 2: Table Of Contents

    Assembly Manual Contents 1.0 GENERAL INFORMATION ................3 Intended Use ..................3 Improper Use..................3 Warranty ................... 3 2.0 SAFETY INFORMATION ................4 Transport and Assembly ..............4 Use of the ModTable Base ..............4 Table Top Limitations ................ 4 Specific Dangers ................

  • Page 3: General Information

    1.0 General Information 1.1 Intended Use Thank you for choosing MultiTable's Manual ModTable! We hope you enjoy your new purchase! Your safety is important to us. Please follow these assembly instructions carefully and thoroughly. Only use your ModTable indoors. Never use the base or top with any other product. The ModTable should only be used for its intended purpose.

  • Page 4: Safety Information

     Should your base or other components require repairs, please contact us. Any repairs or alterations should only completed using approved replacement parts from MultiTable. Replacement parts are available for both in and outside of the warranty time frame. ...

  • Page 5: Box Contents

    3.0 Box Content # Parts 01 Left (L) leg 02 Right (R) leg 03 Foot 04 Left top support 05 Right top support—with brake box 06 Front Center crossbar - with measurements 07 Back Center crossbar 08 Drive shaft 09 Adjustable feet 10 HC (handle) cover 11 HC (handle) gear 12 Handle...

  • Page 6: Important! Read All Before Assembling

    Ensure all parts are in the box.  In case of any damage or missing/incorrect parts, contact customer service at 602.773.6911 or at customerservice@multitable.com  Do not attempt to assemble the ModTable Base if there is any damage or are any missing/incorrect parts.

  • Page 7: Mounting The Feet

    3.4.2 Mounting the Feet Description Left (L) leg Right (R) leg—with gear shaft Foot Spacer Bolts Large Allen wrench  In Photo 2: • Place the right foot on top of the right (R)leg. • The foot should be perpendicular to the crossbars (see Photo 3).

  • Page 8: Mounting The Drive Shaft

    3.4.3 Mounting the Drive Shaft Description Drive shaft Set screws Medium Allen wrench  In Photo 4:  Place left (L) leg in upright position.  Slide the drive shaft over the round metal rod that extends out of the left leg. If the drive shaft will not slide over the metal rod, slightly unscrew set screws, to allow the drive shaft to slide over metal rod.

  • Page 9: Mounting The Center Crossbars

    3.4.4 Mounting the Center Crossbars Description Front Center crossbar—with measurements Back Center crossbar Bolts Large Allen wrench  In Photo 5: Recommended Base Width Without Wheel Kit  Set Base to desired width. Crossbar Base  Attach front and back Measurement Width Size...

  • Page 10: Mounting The Center Crossbars

    3.4.4 Mounting the Center Crossbars Continued Description Set screws Medium Allen wrench  Important! Photo 6:  Fully tighten the set screws in the drive shaft using the Medium Allen wrench. Tighten set screws three times on each side to ensure screws are completely tightened. Set screws MUST be tightened completely for the Base to function properly.

  • Page 11: Mounting The Left Top Support

    3.4.5 Mounting the Left Top Support Part Name Left top support Bolts Large Allen wrench If you purchased a left-handed Base, the left top support will be attached to the right (R) leg, opposite of what the picture below depicts. In Photo 7: ...

  • Page 12: Mounting The Right Top Support

    3.4.7 Mounting the Right Top Support Part Name Right top support—with brake box Bolts Large Allen wrench If you purchased a left-handed Base, the right top support with the brake box will be attached to the left (L) leg, opposite of what the picture below depicts. ...

  • Page 13: Assembling & Mounting The Handle

    3.4.8 Assembling & Mounting the Handle Description Handle Long drive rod Short drive rod Small plastic dot Bolt (already in handle) Small set screw Large Allen wrench Small Allen wrench  In Photo 12:  Tighten the small set screw into the small metal ring. In Photo 13: ...

  • Page 14: Base Test

    3.4.9 Table Top Assembly Part Name Table top screws Important! If you have purchased the Wheel Kit, please skip this section. Continue to the Wheel Kit Assembly Manual now.  Slide handle out of handle bracket, and set aside.  With the assistance of another person, lay table top upside down on the a soft surface, and carefully turn the Base over (upside down), setting it on top of the table top.

  • Page 15: Customer Service

    4.0 Customer Service Contact Information ModTable By MultiTable, LLC 2255 W Desert Cove Ave Suite E Phoenix, AZ 85029 602.773.6911 customerservice@multitable.com www.MultiTable.com Page 15 | ModTable | vs 5.0...
