the product, as the zero point and calibration will stay inside the given tolerances.
This implies that slight offsets from the zero point of 4.0mA (0%LEL) is to be
expected and values up to 4.5mA at room temperature are within specification.
In some environments with excessive heat and/or vibration we have noticed that a
higher percentage of the detectors develop an offset outside the specified
tolerances. These detectors should normally be returned to the factory for service.
An alternative is to do this re-zeroing on site with a dedicated hand held terminal,
or HART® communicator.
Note that "on site" does not mean "in service". Before concluding that re-
!
zero is necessary, proper cleaning of the detector should be done (even
an invisible layer of oil on the lens or mirror can have negative impact on
the zero-point reading). Then, before re-zeroing is conducted, the
detector should be removed from the system and moved to a controlled
environment in a workshop.
6.4.1. Test of zero-point in the workshop
Prior to conducting a re-zero, a controlled checking of the zero level should be done
with a sample flow housing and nitrogen test gas (clean instrument air may be used
if nitrogen is unavailable).
1) Clean the sensor optics again, both mirror and lens.
2) Attach a Sample Flow housing.
3) Connect the power supply and HART® terminal (according to section 0) or a
Hand Held terminal according to its separate operating manual.
4) Switch on power and wait approx. 2 minutes until the output has stabilized.
5) Apply nitrogen gas to the Sample Flow housing.
6) Read current loop output.
7) If output is outside specification, then a re-zero may be applicable.
6.4.2. Re-zeroing with HART® communicator
See section 5.2.4.10.
6.4.3. Re-zeroing with Hand Held Terminal
Refer to the user guide of the Hand Held Terminal (850-816611).
