Installation

Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging and
remove the protective film from all surfaces.
2. Remove the Scoop, Inlet/Outlet hoses and
Sealing Washers from the ice bin.
3. When positioning the ice maker, maintain
a distance of 20cm (7 inches) between the
appliance and walls or other objects for
ventilation. NEVER LOCATE NEXT TO OR
NEAR A HEAT SOURCE.
4. If necessary, adjust the screw legs of the ice
maker to make it level. The efficiency of the
ice maker can be reduced if the appliance is
unevenly located.
5. Connect one end of the corrugated outlet
hose to the water outlet on the rear of the ice
maker.
6. Attach the other end of the hose to a plumbed-
in stand waste pipe or container suitable for
collecting waste water.
7. Place the sealing washers on the water inlet at
the back of the ice maker and attach one end
of the inlet hose.
8. Connect the other end of the inlet hose to the
water supply.
Water inlet
Water outlet
Note: Ensure the end of the
drainage pipe is situated lower
than the Water Outlet valve for
efficient drainage.
4

Operation

Control Panel

Power switch

Making Ice

Note: Before using for the
first time (or after a period of
inactivity), clean the water tank,
ice basket and ice basket shelf.
Use the first ice making cycle to
flush out the system.
Discard the water and ice
created from the first cycle.
1. Ensure the door is closed fully before use.
2. Press the Power switch to the On position [I].
The RUN light illuminates and the appliance
begins the ice making process. Each ice making
cycle takes approximately 25 minutes.
3. When the cubes reach the ice sensor ice
production stops. Production resumes once ice
has been removed from the bin.
4. Press the Power switch to the Off position [O]
at any time to halt the ice making process.
Note: Ensure metal rack is
pushed as far forward as
possible against plastic ice
curtain to allow ice to fall.
Cleaning, Care &
Maintenance
• Always switch off and disconnect the power
supply before cleaning.
• Warm, soapy water is recommended for
cleaning. Cleaning agents may leave harmful
residues. DO NOT wash the base unit, instead
wipe the exterior with a damp cloth.
• A POLAR agent or qualified technician should
carry out repairs if required.
