Application Note
iConverter
®
Managed Fiber Media Converter
Product Family
iConverter XG, XG+ and XGT+
Chassis Installation Guidelines for Airflow and Cooling
Document Number: 002-A0006
Version E
June 2018
Omnitron Systems Technology, Inc.
38 Tesla
Irvine, CA 92618
tel: (949) 250-6510
www.omnitron-systems.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iConverter XG and is the answer not in the manual?

Questions and answers

Related Manuals for OST iConverter XG

Summary of Contents for OST iConverter XG

  • Page 1 ........................Application Note iConverter ® Managed Fiber Media Converter Product Family iConverter XG, XG+ and XGT+ Chassis Installation Guidelines for Airflow and Cooling Document Number: 002-A0006 Version E June 2018 Omnitron Systems Technology, Inc. 38 Tesla Irvine, CA 92618 tel: (949) 250-6510...

  • Page 2: Table Of Contents

    Application Note Doc. No. 002-A0006 Rev E Table of Contents SCOPE ................................3 XG PLUG-IN MODULE REQUIREMENTS ...................3 XG+ AND XGT+ PLUG-IN MODULES REQUIREMENTS ..............5 Installation Guidelines When Using the 19-Module Chassis ............5 Installation Guidelines When Using the 5-Module Chassis ............8 Installation Guidelines When Using the 2-Module Chassis ............9 INSTALLATION GUIDELINES WHEN USING THE 1-MODULE CHASSIS ........10 ©2018 Omnitron Systems Technology, Inc.

  • Page 3: Scope

    Rev E SCOPE This application note provides chassis, power and airflow installation guidelines for the iConverter XG, XG+ and XGT+ plug-in media converter modules. This application note can be used in conjunction with Omnitron Application Note 002-A0007, which provides selection guidelines between the XG and the XG+ products.
  • Page 4 Application Note Doc. No. 002-A0006 Rev E The following chassis are recommended. Model Number Description 8242-x 1-Module Chassis, 8.3W PS, 100-240VAC 8230-x 2-Module Chassis, 8.5W PS, 100-240VAC 8231-x 2-Module Chassis, 16.5W PS, 100-240VAC, with Temp Controlled Fan 8232-x 2-Module Chassis, 16.5W High Airflow PS, 100-240VAC, with Fan 8235-x 2-Module Chassis, 6.6W PS, 18 to 60VDC 8236-x...

  • Page 5: Xg+ And Xgt+ Plug-In Modules Requirements

    Application Note Doc. No. 002-A0006 Rev E XG+ AND XGT+ PLUG-IN MODULES REQUIREMENTS The XG+ and XGT+ models shown in Table 4a and 4b can generate elevated levels of heat depending on the installed transceivers. The appropriate chassis must be selected to meet the appropriate power and airflow requirements for these modules.
  • Page 6 Application Note Doc. No. 002-A0006 Rev E Power Supply Supported XG+/XGT+ Module Chassis Slot Number Chassis Slot Numbers Slot 20 Slots 14 - 19 Slot 21 Slots 8 - 13 Slot 22 Slots 1 - 7 Table 6. 19-Module Chassis Power Supply and XG+/XGT+ Module Slot Positions The figure below shows the relationship between the power supply slots and the appropriate slots for the installed XG+/XGT+ modules.
  • Page 7 Application Note Doc. No. 002-A0006 Rev E Figure 2. Properly Configured 19-Module Chassis and XG+ Modules A maximum of nine (9) XG+/XGT+ modules can be installed in a 19-Module Chassis when configured with three (3) 120W High Airflow power supplies installed. The following figure shows a properly configured 19-Module Chassis fully populated with one NMM2, nine XG+ modules, blank panels and three 120W High Airflow power supplies.

  • Page 8: Installation Guidelines When Using The 5-Module Chassis

    Application Note Doc. No. 002-A0006 Rev E The modules installed in the chassis may need to be repositioned in order to meet the airflow and spacing requirements of the XG+/XGT+ modules as stated in this section. Model Number Description 8201-9 Spare 19-Module Chassis with one (1) 120W High AirFlow PS, 100-240VAC, with Fan 8207-9 Spare 19-Module Chassis with one (1) 120W High Airflow PS, 36 to 60VDC, with Fan...

  • Page 9: Installation Guidelines When Using The 2-Module Chassis

    Application Note Doc. No. 002-A0006 Rev E Model Number Description 8221-9 Spare 5-Module Chassis with one (1) 66W High AirFlow PS, 100-240VAC, with Fan 8227-9 Spare 5-Module Chassis with one (1) 66W High Airflow PS, 36 to 60VDC, with Fan Table 9.

  • Page 10: Installation Guidelines When Using The 1-Module Chassis

    Application Note Doc. No. 002-A0006 Rev E NOTES: 1. All empty or unused slots must have a blank panel installed. 2. An XG module can be installed in a High Airflow chassis. 3. Only one XG+/XGT+ module can be installed in a 2-Module Chassis. The XG+/XGT+ module must be installed in the bottom slot of the chassis as shown in Figure 5. Another iConverter module can be installed in the top slot.
