Mini DisplayPort™ to 4K-HDMI®/DVI/4K-DisplayPort® Adapter
1) Connect the ADAPTER to the Mini DisplayPort/Thunderbolt 2 port of the COMPUTER
2) Connect an HDMI/DVI/DP CABLE (sold separately) from the ADAPTER to the DISPLAY
3)
Select the HDMI/DVI/DP input setting from the menu of the connected DISPLAY
4)
Select a compatible VIDEO resolution and refresh rate from the computer
5) Adjust the computer AUDIO output settings for HDMI or DisplayPort
Connection Notes
•
SINGE OUTPUT with one display connection at a time (HDMI or DVI or DP)
•
WINDOWS & MAC COMPATIBLE with Thunderbolt™ 2 or Mini DisplayPort ports
•
HDMI/DVI IS NOT BI-DIRECTIONAL and converts only from MiniDP to HDMI or DVI
•
HDMI/DP VIDEO RESOLUTION up to 3840 x 2160 @ 30 Hz
•
DVI VIDEO RESOLUTION up to 1920x1200 @ 60 Hz including 1080p
•
AUDIO SUPPORT for HDMI and DisplayPort with compatible equipment
•
AUDIO IS NOT SUPPORTED BY DVI and must be transmitted separately
•
MACS BEFORE 2010 do not output audio over Mini DisplayPort
•
EASY-GRIP TREADS on the connector assist in cable unplugging to prevent damage
•
HDCP SUPPORT for copy protected video with HDCP compliant equipment
•
DUST CAP protects the Mini DisplayPort connector on the adapter when traveling
Apple, Mac, MacBook, MacBook Air, MacBook Pro, Mac Pro, and iMac are trademarks of Apple Inc.
HDMI and High-Definition Multimedia Interface are either registered trademarks or trademarks of HDMI Licensing, LLC in the United States and/or other countries
Thunderbolt is a trademark of Intel Corporation in the U.S. and/or other countries.
Contact support@cablematters.com for questions
Model 101012
Advertisement
Related Manuals for cable matters 101012
Summary of Contents for cable matters 101012
- Page 1 Model 101012 Mini DisplayPort™ to 4K-HDMI®/DVI/4K-DisplayPort® Adapter 1) Connect the ADAPTER to the Mini DisplayPort/Thunderbolt 2 port of the COMPUTER 2) Connect an HDMI/DVI/DP CABLE (sold separately) from the ADAPTER to the DISPLAY Select the HDMI/DVI/DP input setting from the menu of the connected DISPLAY...
- Page 2 IDEO ETTINGS IN INDOWS Connect the Adapter and the cable Select the HDMI/DVI/DP input from the con- nected display menu Search for Display Settings in Windows Select to Duplicate or Extend the display (Note: Click and drag the program to the display in Extended Mode) Click Apply to save the settings Select Display Adapter Properties...
- Page 3 IDEO ETTINGS IN 1) Connect the Adapter and the cable 2) Select HDMI/DVI/DP input on the display 3) Open the Apple Menu on your computer 4) Select System Preferences 5) Click the Displays icon 6) Click the Arrangement tab Choose to Duplicate or Extend the display ...
- Page 4 During this period, the products may be returned for repair, or replaced with equivalent products at our discretion. The warranty covers parts and labor costs only. Cable Matters does not warrant its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
