SOUNDMASTER TR65 Manual

GENERAL CONTROLS
1. ON / OFF switch
2. BAND button
3. SLEEP button
4. ALARM button
5. M button (MEMO / SET)
6. MEMO button ▲/▼
7. MIN.◄ ◄ / ► ►HOUR button
POWER SUPPLY
1. Remove the battery compartment door by applying thumb pressure to area indicated on
battery door and then lift the door out and off the cabinet.
2. Insert 4 x 1.5 V "D" / R20 / UM1 batteries with the + and - marks correctly aligned (not
included) into the compartment.
3. Replace the compartment door.
Notes on batteries
• Do not mix different types of batteries or old batteries with new ones.
• Never recharge the batteries, apply heat to them or take them apart.
• Battery shall not be exposed to excessive heat such as sunshine,fire or the like.
• Attention should be drawn to the environmental aspects of battery disposal.
• The batteries need to be replaced when:
The volume decreases, or sound is distorted during operation.
NOTE: In order to avoid leakage, always remove the batteries when unit will not be used for a
long period of time.
R-2535N IB SOUN 001 REV0.indd 4
8. AUX IN Jack
9. PHONE Jack
10. VOLUME control
11. FM telescopic antenna
12. AC power cord
13. Battery Compartment
GB - 1
CONNECTING THE AUX
Connect your auxiliary source ( e.g.mp3 player) to the AUX input jack on the right side of the
unit, the unit will change to AUX function automatically.
IMPORTANT NOTICE
Automatic standby mode
To comply with the ErP2 directive, the unit automatically switches to standby after approx. 11
minutes without a signal. (For instance in CD-Stop mode). To switch the unit on again, please
follow the instructions mentioned in instruction manual.
POWER ON / OFF THE UNIT
1. Press the ON/OFF to turn on the radio. The display will change to show radio frequency.
2. Press the ON/OFF to turn off the radio. The display will revert to current time.
SET CLOCK
After the batteries are installed, the display will show "00:00".
1. Press MEMO/SET once and you will see the flashing display.
2. Press MIN. ◄ ◄ or ► ►HOUR to set the time.
3. Press MEMO/SET again when finished.
RADIO
Using the radio
1. Press the ON / OFF to turn on the radio.
2. Press BAND to select AM or FM bands.
3. Press MIN. ◄ ◄ / ► ►HOUR or to tune to your desired radio station.
4. Adjust the volume by (10).
To enhance radio reception ability:
FM: Extend and rotate the antenna.
AM: Rotate and move the unit horizontally for optimum reception.
Saving Preset Stations
1. Tune to a station to be saved as a preset station ( see "Using the Radio").
2. Press MEMO / SET once and you will see a flashing 'MEMORY' on the display.
3. Press MEMO button ▲/▼ to select a preset number.
4. Press MEMO / SET to save station as selected preset number.
5. Repeat above steps to preset a maximum of 10 stations for AM and FM respectively.
Selecting Preset Stations
1. Make sure you are in preset mode.
2. Press MEMO button ▲/▼ to select a preset number.
GB - 2
