Parts List For Conveyor Assembly - SuperMax SUPERBRUSH 36 Owner's Manual

32 S B
UPER RUSH
S
UPER
Ref. Description
Number
1 1/4˝-20x1/2˝ ROUND HEAD MACH SCREW
2 WASHER, 1/4 INTERNAL TOOTH LOCK
3 SWITCH BRACKET
4 SWITCH BOX
5 ON/OFF SWITCH
6 1/4˝-20 HEX NUT
7 LARGE STRAIN RELIEF
8 CORD SET, SINGLE PHASE, 32˝
CORD SET, THREE PHASE, 32˝
9 CONTROLLER, 180 V, VARIABLE SPEED
INCLUDING KNOB, NUT AND DIAL PLATE
10 SMALL STRAIN RELIEF
11 FUSE HOLDER
12 180-VOLT GEAR MOTOR
13 CORD SET, MAIN W/PLUG, SINGLE PHASE
CORD SET, MAIN, NO PLUG, THREE PHASE
14 V-BELT
15 RETAINING CLIP
16 5/16˝-18x3/8˝ SOCKET HEAD SET SCREW
17 CORD SET, SINGLE PHASE, 66˝
CORD SET, THREE PHASE, 66˝
18 KEY STOCK, 1/4x1 3/4
19 FUSE, 3/4 AMP
21 PULLEY, DRIVE, VARIABLE SPEED
22 #10-24 RETAINING NUT
23 LOWER INNER BELT GUARD
24 5/16˝-18 FLANGED LOCK NUT
25 3/8˝ WROUGHT WASHER
26 MOTOR, 5 HP. TEFC, SINGLE PHASE
MOTOR, 5 HP. TEFC, THREE PHASE
27 5/16˝-18x3/4˝ CARRIAGE BOLT
28 5/16˝-18x1/2˝ HEX HEAD BOLT
29 CONTROL HOUSING
30 5/16˝-18 RETAINING NUT
31 SCREW, 5/16-18x1/4 SOCKET HEAD SET SCREW
32 COUPLING (CONVEYOR)
33 CONTROL BOX BASE BRACKET
34 #10-24x3/8˝ SLOTTED HEX HEAD SCREW
35 #10-24 RETAINING NUT
36 BOTTOM COVER
37 RIGHT SIDE RAIL
O ' M
WNER S ANUAL
B C
RUSH ONVEYOR
& M P
OTOR ARTS
Part Number
SB24
L
IST
Both SB36
Models
10-3205
11-0504
40-5005
72-5400-2
72-5400-1
12-0001
72-6104
72-5315
72-5305
72-1260
72-6102
72-6202
71-1171
72-5430
72-5305
50-2029
72-6210
10-2903
72-5315
72-5305
N/A
72-6201
50-0704
20-1157
40-1000
12-0207
11-0104
71-0502
71-1503
10-1203
10-9101
40-5012
20-1159
10-8902
30-3102
40-4115
10-3803
20-1155
40-4116
40-4106
Qty./
Unit
3
3
1
1
1
3
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
4
2
1
1
4
4
1
4
2
1
1
2
2
1
1
