Dishwasher Features - KitchenAid KDTE334G User Instructions

Silverware Basket
Silverware basket lids:
Use silverware basket lids to provide optimal spacing and best
cleaning performance.
NOTE: If your silverware does not fit into the designated slots,
push tabs inward on either end and lift lid off of the silverware
baskets. Mix silverware types to keep them separated. Load
knives down, forks up, and alternate spoons for best cleaning
results.
Easy-to-Remove Third-Level Rack (on some models)
If additional space is
needed in the upper
rack, the third-level
rack can easily be
removed.
To remove, fully
extend rack until it
stops. Then, open the
track stops on each
side and slide the rack
out to remove.
Low-profile items such
as serving utensils
and silverware may
be loaded on the third
level rack.
Cup and Stemware Holder
Fold down the extra shelf on the top rack to hold additional cups,
stemware, or long items such as utensils and spatulas. For best
results on cups, stagger the spacing so that the cups on the shelf
are not directly above the cups below.

Dishwasher Features

A. Track stop B. Track
FLEXI-FOLD DOWN™ Adjustable Tines
The row of tines on the left-hand and
right-hand sides of the top rack can be
adjusted to make room for a variety
of dishes.
To adjust the fold-down tines:
1. Grasp the tip of the tine that is in the
tine holder.
2. Gently push the tine out of the holder.
3. Lay the tines down, toward the center
of the rack.
Premium Adjustable 2-Position Top Rack
You can raise or lower the top rack to fit tall items in either the top
or bottom rack. Adjusters are located on each side of the top rack.
To raise the rack:
Press both rack adjuster
thumb levers and lift the rack
until it is in the up position
and level.
To lower the rack:
Press both rack adjuster
thumb levers and slide the
rack to its down position
and level.
NOTE: The top rack must be level.
Removable Top Rack
The removable top rack
allows you to wash
larger items such as
pots, roasters, and
cookie sheets in the
bottom rack.
IMPORTANT:
Remove dishes prior to
removing the top rack
from the dishwasher.
To remove the rack:
To gain access to the
removable tabs on the
tracks/rails, pull the
upper rack forward
about halfway out of
the tub.
On one side, press the tab on the track in and pull up the front
end of the rack, out of the track. Then repeat this step on the
other side to completely remove the front end of the rack.
Then remove the rack by pulling the back end out using a forward
and upward motion.
To replace the rack:
Pull the tracks forward about halfway out of the tub.
Along the sides of the racks are round attachment tabs. Align
the rack's back end attachment tabs with the cutout in the track.
Push down into place.
Pull the tracks completely out, and align the rack's front end
attachment tabs with the cutout in the track. Push down into
place. You will hear a snap when the front end of the rack is
secured into place on each side.
11
