Ip.Access nanoLTE E40 Product Manual

Single mode lte only access point
Hide thumbs
Table of Contents

Advertisement

Quick Links

nanoLTE E40 AP Product Description
NANO_GST_43310
101_0.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the nanoLTE E40 and is the answer not in the manual?

Questions and answers

Related Manuals for Ip.Access nanoLTE E40

Summary of Contents for Ip.Access nanoLTE E40

  • Page 1 E40 AP Product Description NANO_GST_43310 101_0.5...
  • Page 2 Notices This document is provided to you by or on behalf of ip.access Ltd ("ip.access"). © ip.access Limited 2016. The documentation and any software described herein and/or provided to you in conjunction with this documentation contain proprietary and confidential information of ip.access and may only be used subject to a license agreement containing restrictions on use and disclosure.
  • Page 3 Revision History Version Change Summary Date Author 101_0.1 Updated for N4G_1.1 15 Dec 2015 101_0.2 Update details for E40 US band support 18 Jan 2016 101_0.3 Cosmetic adjustments 31 Mar 2016 101_0.4 Update references to other manuals 22 Jun 2016 101_0.5 Add hardware capability equivalence statement for 248 and 278 19 Jul 2016...

  • Page 4: Table Of Contents

    Compliance to Standards ..............10 Electromagnetic Compatibility (EMC) .............. 10 Storage ......................10 Transportation....................11 Safety....................... 11 Hardware Equivalence for 248 and 278 Product Variants ....... 11 nanoLTE E40 AP Product Description NANO_GST_43310 v101_0.5 for N4G_1.1 © ip.access Limited 2016 Page i...

  • Page 5: Introduction

    Introduction The nanoLTE E40 AP (E40) is a single mode LTE only Access Point, built on advanced DSP technology. Supporting 2x2 MIMO with an output power of +21dBm per port (at the antenna connector), the E40 provides comprehensive LTE operation for Enterprise deployments.

  • Page 6: Key Features

    Key Features The key features of the nanoLTE E40 AP are: Feature Details 3GPP Compliance Compliant to [36.104]. Number of RF Carriers Single Carrier. Bandwidth The nanoLTE AP supports the following bandwidths: • 5MHz • 10MHz • 15MHz • 20MHz MIMO 2x2 MIMO-Single User Downlink only.
  • Page 7 The data rates achieved at the application layer may vary subject to radio conditions, available backhaul bandwidth and number of simultaneous active users. nanoLTE E40 AP Product Description Key Features NANO_GST_43310 v101_0.5 for N4G_1.1 © ip.access Limited 2016...

  • Page 8: Product Details

    The data rates achieved at the application layer may vary subject to radio conditions, available backhaul bandwidth and number of simultaneous active users. Operational Range With the standard antennae, the nanoLTE E40 AP has an approximate maximum range of 700m with 0dB path loss. 3.3.1 Long Range Extension (LRE) The LRE feature provides the option to increase the range of the nanoLTE AP by connecting the AP to an external PA.

  • Page 9: Oa&M

    Mechanical Design and Form Factor Dimensions - W x H x D 202mm x 46mm x 268mm Weight - E40 unit only Approximately 1.2Kg nanoLTE E40 AP Product Description Product Details NANO_GST_43310 v101_0.5 for N4G_1.1 © ip.access Limited 2016 Page 5...

  • Page 10: Physical Interfaces

    When used in SISO mode, it is possible to have one antenna for the Tx path and one antenna for the Rx path. The nanoLTE E40 AP has 2 antenna elements housed internally within its external plastic enclosure. These are directly connected to the main PCB assembly by means of SMA connectors.

  • Page 11: Network Interfaces

    10% to 70% non-condensing Storage Conditions -20C to +80C 0% to 90% non-condensing The nanoLTE E40 AP has an ingress rating of IP40 in accordance with EN 60529 and is cooled passively (i.e. no internal fan). nanoLTE E40 AP Product Description Product Details NANO_GST_43310 v101_0.5 for N4G_1.1 ©...

  • Page 12: Accessories

    Although IPsec is shown in this architecture, the general functionality of the nanoLTE E40 AP has no dependency on the use of IPsec. In environments where the end-to-end backhaul between nanoLTE E40 APs and the EPC is fully secure, the use of IPsec is optional.

  • Page 13: Nos Oa&M Support For Lte Aps

    LTE, 3G and 2G neighbours for handover, reselection and CSFB. Note: CSFB is only used when the UE or the core network does not support VoLTE. nanoLTE E40 AP Product Description Product Details NANO_GST_43310 v101_0.5 for N4G_1.1 © ip.access Limited 2016...

  • Page 14: Compliance To Standards

    LTE FDD. Storage The nanoLTE Access Point complies with the following standard for storage: • EN 300 019-1-1 Class 1.1 “Partly temperature-controlled storage". nanoLTE E40 AP Product Description Compliance to Standards NANO_GST_43310 v101_0.5 for N4G_1.1 © ip.access Limited 2016 Page 10...

  • Page 15: Transportation

    The RF Technology (LTE), frequencies and power level are identical between both variants. In respect of the 248M and 278M variants of the nanoLTE E40 AP, ip.access has reviewed the Software Changes section of the FCC Permissive Changes Document dated 16th Oct 2015.
