EnGenius ENH1350EXT User Manual page 15

Physical Interface(ENH1350EXT)
Dimensions and Weights
Length: 6.83"
Width: 4.38"
Depth: 1.19"
Weight: TBD
1 2.4 GHz Antennas: Detachable 5.17 dBi 2.4 GHz Omni-directional
2 5 GHz Antennas Detachable 5.17 dBi 5 GHz Omni-directional
3 LAN Port (802.3af and Proprietary 54V PoE Input): Ethernet
port for RJ-45 cable.
4 LED Indicators: LED lights for Power, LAN Port, 2.4 GHz
Connection and 5 GHz Connection.
5 Mounting Holes: Using the provided hardware, the ENH1350EXT
can be attached to a wall or pole.
1 2
3
2
1
15
5
4
