- Page 1 Business Solutions User Manual ENH900EXT version 1.1 Dual Band Long Range Wireless N900 Outdoor Access Point...
- Page 2 IMPORTANT To install this Access Point please refer to the Quick Installation Guide included in the product packaging.
-
Page 3: Table Of Contents
Chapter 2 Before You Begin..........11 2.4GHz Mesh Link Settings............50 Computer Settings............... 12 Guest Network Settings............51 Hardware Installation..............16 Mounting the ENH900EXT............17 Chapter 8 Management ............52 Management VLAN Settings..........53 Chapter 3 Configuring Your Access Point......20 Wi-Fi Multi Media................. 54 Default Settings./Web Configuration........ 21... -
Page 4: Chapter 1 Product Overview
Chapter 1 Product Overview... -
Page 5: Key Features/Introduction
Features and specifications subject to change without notice. Trademarks and registered trademarks are the property of their respective owners. For United States of America: Copyright © 2014 EnGenius Technologies, Inc. All rights reserved. -
Page 6: System Requirements
The following are the Minimum System Requirements in mobile devices in common outdoor areas. order to configure the device. The ENH900EXT is easy to install in virtually any location • Computer with an Ethernet interface or wireless network capability with its included PoE (Power over Ethernet) injector for • Windows OS (XP, Vista, 7, 8, 10), Mac OS, or Linux-based operating... -
Page 7: Package Contents
Package Contents The ENH900EXT package contains the following items:* • ENH900EXT Access Point • 3 detachable 5 dBi 2.4 GHz Omni-directional Antenna • 3 detachable 7 dBi 5 GHz Omni-directional Antenna • Power Adapter (48V/0.8A) • PoE Injector (EPE-48GR) • Grounding Cable • Pole Mount Bracket •... -
Page 8: Technical Specifications
Technical Specifications WDS Detail Standard: WDS AP IEEE802.11a/n on 5 GHz WDS Bridge IEEE802.11b/g/n on 2.4 GHz WDS Station IEEE802.3at Antenna Mesh Detail 6 External N-type Antenna Mesh AP Mesh Point 3 x detachable 5 dBi 2.4 GHz Omni-directional Antennas 3 x detachable 7 dBi 5 GHz Omni-directional Antennas Management Auto Channel Selection Physical Interface... - Page 9 Security RF Specification (Aggregated Value) WEP Encryption - 64/128/152 bit Channel Data Rate Tx Power Rx Sensitivity WPA/WPA2 Personal (WPA-PSK using TKIP or AES) 802.11b 2.4GHz 1Mbps WPA/WPA2 Enterprise (WPA-PSK using TKIP or AES) 2Mbps Hides SSID in beacons 5.5Mbps MAC address filtering, up to 32 MACs per SSID 11Mbps Wireless STA (Client) connection list Https Support 802.11g 2.4GHz 6Mbps...
-
Page 10: Physical Interface
4 LAN Port 2 (802.3af PSE Output): Ethernet port for RJ-45 cable. 5 LED Indicators: LED lights for Power, LAN Port 1, LAN Port 2, 2.4 GHz Connection and 5 GHz Connection. 6 Ground 7 Mounting Holes: Using the provided hardware, the ENH900EXT can be attached to a wall or pole. -
Page 11: Chapter 2 Before You Begin
Chapter 2 Before You Begin... -
Page 12: Computer Settings
Computer Settings Windows XP/Windows 7/Windows 8/Windows 1b. Move your mouse to the lower right hot corner to display the Charms Bar and select the Control Panel in Windows 8 OS. In order to use the Access Point, you must first configure the TCP/IPv4 connection of your Windows OS computer system. 1a. Click the Start button and open the Control Panel Windows 8 1c. - Page 13 4. Select Internet Protocol Version 4 (TCP/IPv4) and then 2a. In Windows XP, click Network Connections. select Properties. 2b. In Windows 7/Windows 8/Windows 10, click View Network Status and Tasks in the Network and Internet section, then select Change adapter settings. 3.
- Page 14 Note: Ensure that the IP address and Subnet mask are on the same subnet as the device. For example: Access Point IP address: 192.168.1.1 PC I P a ddress: 1 92.168.1.2 – 1 92.168.1.255 PC Subnet mask: 255.255.255.0...
- Page 15 2. Select Network in the Internet & Network section. Note: Ensure that the IP address and Subnet mask are on the same subnet as the device. For example: ENH900EXT IP address: 192.168.1.1 PC I P a ddress: 1 92.168.1.2 – 1 92.168.1.255 PC Subnet mask: 255.255.255.0 6.
-
Page 16: Hardware Installation
Ensure that the 2.4 GHz/5 GHz WLAN light is on (it will be green for both 5 GHz and 2.4 GHz). c) Ensure that (Computer/ENH900EXT Power Outlet Connection) light is on (it will be green). d) Once all three lights are on, proceed to set up the Note: The Access Point supports both IEEE 802.3at PoE... -
Page 17: Mounting The Enh900Ext
Mounting the ENH900EXT Using the provided hardware, the ENH900EXT can be attached to a wall or a pole. 1. Wall Mount Kit: 260x180x7 (mm) 2. Pole Mount Kit 140x112x33 (mm) (10.2" x 7.09" x 0.28") (5.51" x 4.41" x 1.30") 3. Pipe 63.5 (D) x 12.7 (mm) 4. - Page 18 Using the provided hardware, the ENH900EXT can be attached to a wall or a pole. To attach the ENH900EXT to a wall using wall 3. Place the lock and flat washers on the four hex cap screws mounting kit. and drive the screws to attach the bracket to the back of the Access Point.
- Page 19 To attach the ENH900EXT to a pole using the provided pole mounting kit: 1. Place the lock and flat washers on the four hex cap screws 3. Thread the open end of the Pole Strap through the two and drive the screws to attach the bracket to the back of tabs on the Pole Mount Bracket .
-
Page 20: Chapter 3 Configuring Your Access Point
Chapter 3 Configuring Your Access Point... -
Page 21: Default Settings./Web Configuration
3. If successful, you will be logged in and see the Chrome) and enter the IP Address http://192.168.1.1 ENH900EXT User Interface. Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address. -
Page 22: Chapter 4 Building A Wireless Network
Chapter 4 Building a Wireless Network... -
Page 23: Access Point Mode
The ENH900EXT has the ability to operate in various modes. This chapter describes the operating modes of the ENH900EXT. Access Point Mode In Access Point Mode, ENH900EXT behaves likes a central connection for stations or clients that support IEEE 802.11a/b/g/n networks. The stations and clients must be configured to use the same SSID (Service Set Identifier) and security password to associate with the ENH900EXT. The ENH900EXT supports up to eight SSIDs per band at the same time for secure access. ENH900EXT Access Point Client Client 2.4 GHz... - Page 24 The ENH900EXT can be used as a centralized Outdoor Access Point with which other EnGenius Wireless N 2.4 or 5 GHz Outdoor Client Bridges can associate; leveraging the long-range capability of their internal high-gain directional antennas, resulting in a very cost-effective solution to expand a company network over a multiple building campus.
-
Page 25: Wds Ap Mode
WDS AP Mode The ENH900EXT also supports WDS AP mode. This operating mode allows wireless connections to the ENH900EXT using WDS technology. In this mode, configure the MAC addresses in both Access Points to enlarge the wireless area by enabling WDS Link settings. WDS supports up to four (4) AP MAC addresses. ENH900EXT ENH900EXT WDS AP WDS AP 5 GHz... -
Page 26: Wds Bridge Mode
ENH900EXT device. Use this mode when two wired LANs located a small distance apart want to communicate with each other. The best solution is to use the ENH900EXT to wirelessly connect two wired LANs, as shown in the following diagram. -
Page 27: Wds Station Mode
WDS Station Mode Station mode expands the WDS by receiving a wireless signal/service and sharing it through the Ethernet port. ENH900EXT WDS AP on both 5 GHz & 2.4 GHz ENH900EXT ENH900EXT WDS Station WDS Station ENH900EXT WDS Station... -
Page 28: Ap Mesh Mode
AP Mesh Mode Under the AP Mesh mode, the ENH900EXT can be used as the central connection hub for station or clients that support IEEE 802.11 b/g/n network. Under this mode, the ENH900EXT can be configured with the same Mesh SSID and security password in order to associate with other ENH900EXTs, as well as connect with clients under the same SSID and encryption signatures. -
Page 29: Mesh Only Mode
Mesh Only Mode Under the Mesh-only mode, the ENH900EXT can be configured with the same Mesh SSID and security password in order to associate with other Mesh enabled ENH900EXT ENH900EXTs, instead of connecting with clients. Access Point ENH900EXT ENH900EXT Access Point... -
Page 30: Chapter 5 Status
Chapter 5 Status... -
Page 31: Main Status
Main Status Save Changes Device Status This page lets you save and apply the settings shown under Clicking the Device Status link under the Overview menu Unsaved changes list, or cancel the unsaved changes and shows the status information about the current operating revert to the previous settings that were in effect. - Page 32 DNS Address. • The Wireless LAN Information 2.4 GHz/5 GHz section shows wireless information such as Operating Mode, Frequency, and Channel. Since the ENH900EXT supports multiple-SSIDs, information about each SSID, the ESSID, and security settings, are displayed Note: Profile Settings are only applicable in Access Point and WDS AP modes.
- Page 33 The Wireless Mesh Information - 2.4 GHz section • shows wireless information such as Operation Mode, Wireless Mode, Channel Bandwidth, Frequency/ Channel, Mesh SSID and Mesh Security.
-
Page 34: Connection
Click the connection link under the Overview menu displays Click the connection link under the Overview menu. This the connection list of clients associated to the ENH900EXT’s page displays the current status of the WDS link, including 2.4 GHz/5 GHz, along with the MAC addresses and signal WDS Link ID, MAC Address, Link Status and RSSI. - Page 35 The Mesh Link List Monitor the 2.4GHz Mesh Link List under the status menu. The page will display the current status of the Mesh Links under the Mesh AP mode and Mesh nodes under the Mesh Only mode. Note: Only Applicable in the Mesh AP and Mesh Only mode.
-
Page 36: Chapter 6 Network
Chapter 6 Network... -
Page 37: Basic Ip Settings
Basic IP Settings IPv4/IPv6 Settings IP Network Settings: Select whether the device IP address This page allows you to modify the device’s IP settings. will use a static IP address specified in the IP address field or be obtained automatically when the device connects to a DHCP server. IP Address: The IP address of this device. Subnet Mask: The IP Subnet mask of this device. -
Page 38: Spanning Tree Protocol Setting
Spanning Tree Protocol (STP) Settings This page allows you to modify the Spanning Tree settings. Spanning Tree Status: Enables or disables the Spanning Enabling the Spanning Tree protocol will prevent network Tree function. loops in your LAN network. Hello Time: Specifies Bridge Hello Time in seconds. This value determines how often the device sends handshake packets to communicate information about the topology throughout the entire Bridged Local Area Network. -
Page 39: Chapter 7 2.4 Ghz/5 Ghz Wireless
Chapter 7 2.4 GHz & 5 GHz Wireless... -
Page 40: Wireless Settings
Wireless Wireless Settings Device Name: Enter a name for the device. The name you type appears in SNMP management. This name is not the SSID and is not broadcast to other devices. Band Steering: Enable Band Steering to send 802.11n clients to the 5 GHz band, where 802.11b/g clients cannot go, and leave 802.11b/g clients in 2.4GHz to operate at their slower rates. -
Page 41: 2.4 Ghz/5 Ghz Wireless Network
Data Rate: Select a data rate from the drop-down list. The data rate affects throughput of data in the ENH900EXT. Select the best balance for you and your network but note that the lower the data rate, the lower the throughput, though transmission distance is also lowered. - Page 42 speed connections. Save: Click Save to confirm the changes or Cancel to cancel and return to previous settings.
-
Page 43: 2.4 Ghz/5 Ghz Ssid Profile
2.4 GHz/5 GHz SSID Profile Current Profile: You can configure up to sixteen (16) different SSIDs (eight (8) per band). If multiple client devices will be accessing the network, you can arrange the devices into SSID groups. Click Edit to configure the profile and check whether you want to enable extra SSID. SSID: Specifies the SSID for the current profile. -
Page 44: Wireless Security
Wireless Security The Wireless Security section lets you configure the Auth Type: Select Open System or Shared Key. ENH900EXT’s security modes: WEP, WPA-PSK, WPA2-PSK, Input Type: WPA-PSK Mixed, WPA, WPA2, and WPA Mixed. It is strongly ASCII: Regular Text (recommended) recommend that you use WPA2-PSK. -
Page 45: Wireless Mac Filtering
MAC address to restrict permission to Deny MAC in the list, or Allow MAC in the list. access the ENH900EXT. The default setting is: Disable MAC Address: Enter the MAC address of the wireless client. Wireless MAC Filter. -
Page 46: Wireless Advanced
Wireless Advanced WPA-PSK (WPA Pre-Shared Key) Encryption: Wireless Traffic Shaping Traffic shaping regulates the flow of packets leaving an interface to deliver improved Quality of Service. Encryption: Select the WPA encryption type you would like. Please ensure that your wireless clients use the same settings. -
Page 47: Wps Mixed-Enterprise: Ap/Wds Ap Mode
WPA Mixed-Enterprise: Access Point / WDS AP mode Radius Accounting Server: Enter the IP address of the Radius accounting server. Radius Accounting Port Enter the port number used for connections to the Radius accounting server. Radius Accounting Secret: Enter the secret required to connect to the Radius accounting server. -
Page 48: Fast Roaming
Fast Roaming Enable the function to serve mobile client devices that roam from Access Point to Access Point. Some applications running on Client devices require fast re-association when they roam to a different Access Point Please enter the settings of the SSID and initialize the Security Enable Fast Roaming: Enable or disable fast roaming mode to WPA enterprise, as well as to set the Radius Server feature. -
Page 49: Wds Link Settings
WDS Link Settings 2.4 GHz/5 GHz WDS Link Settings Using the WDS (Wireless Distribution System) feature will allow a network administrator or installer to connect to Access Points wirelessly. Doing so will extend the wired infrastructure to locations where cabling is not possible or inefficient to implement. -
Page 50: 2.4Ghz Mesh Link Settings
2.4GHz Mesh Link Settings AES Passphrase: Enter the key values you wish to uses. Other Access Points must use the same key to establish Users can choose the 2.4GHz band for Mesh operation. a mesh link Mesh Settings Mesh SSID: To create a mesh network, please enter the Mesh SSID of the Access Point that you wish to include in the Mesh. -
Page 51: Guest Network Settings
Guest Network Settings Ending IP Address: The last IP Address in the range of addresses assigned by the DHCP server. Adding a guest network allows visitors to use the Internet Fast Handover without giving out your office or company wireless security key. -
Page 52: Chapter 8 Management
Chapter 8 Management... -
Page 53: Management Vlan Settings
LAN. Note: If you reconfigure the Management VLAN ID, you Note: Only applicable in Access Point and WDS AP may lose your connection to the ENH900EXT. Verify modes. that the DHCP server supports the reconfigured VLAN ID and then reconnect to the ENH900EXT using the new IP address. -
Page 54: Wi-Fi Multi Media
Wi-Fi Multi Media (WMM) Class (AC) over the other, such as giving voice or video priority over email. This feature provide QoS (Quality of Service) for prioritizing multimedia traffic on the network. WMM prioritization achieves the goal of minimizing delay in a wireless network for time-sensitive applications such as video streaming. -
Page 55: Advanced Settings
Advanced Settings SNMP Settings Location: Specifies the location of the device. Community Name (Read Only): Specifies the password This page allows you to assign the Contact Details, Location, for the SNMP community for read only access. Community Name, and Trap Settings for a Simple Network Management Protocol (SNMP). SNMP is a networking Community Name (Read/Write): Specifies the password management protocol used to monitor network attached for the SNMP community with read/write access. -
Page 56: Cli Settings/Email Alert
CLI Settings Email Alert You can use the Email Alert feature to send messages to the configured email address when particular system events occur. Note: Do NOT use your personal email address as it can unnecessarily expose your personal email login credentials. CLI: The Command Line Interface (CLI) allows you to type Use a separate email account made for this feature instead commands instead of choosing them from a menu or... - Page 57 Username: Enter the username for the email account that will be used to send emails. Password: Enter the password for the email account that will be used to send emails. SMTP Server: Enter the IP address or hostname of the outgoing SMTP server.
-
Page 58: Time Zone
Start: Select the day, month, and time when daylight This page allows you to set the internal clock of the savings time starts. ENH900EXT. End: Select the day, month, and time when daylight sav- ings times ends. Manually Set Date and Time: Manually specify the date and time. -
Page 59: Auto Reboot Settings
Auto Reboot Setting: Enables or disables the Auto Reboot function. Frequency of Auto Reboot: Specifies how often you wish to reboot the ENH900EXT by Min, Hour, Day or Week. Timer: Select the day and enter the time you would like to reboot automatically. -
Page 60: Wi-Fi Scheduler
Wi-Fi Scheduler drop-down list. Day(s): Place a checkmark in the boxes for the desired days The Wi-Fi Scheduler can be created for use in enforcing or select the All Week radio button to select all seven days rules. For example, if you wish to restrict web access to of the week. -
Page 61: Tools
(via IP). This page allows you to analyze the connection quality of Traceroute Target: Enter the IP address or domain name the ENH900EXT and trace the routing table to a target in you wish to trace. the network. Start Traceroute: Click Start Traceroute to begin the trace route operation. - Page 62 Speed Test Parameters / LED Control LED Control This page allows you to control LED on/off for Power, LAN Power: Enables or disables the Power LED indicator. interface, or 2.4 GHz/5 GHz WLAN interface. LAN: Enables or disables the LAN LED indicator. WLAN-2.4 GHz: Enables or disables the WLAN-2.4 GHz LED indicator.
-
Page 63: Account/Firmware
Firmware Account This page allows you to change the ENH900EXT username Firmware Upgrade and password. By default, the username is: admin and the This page allows you to upgrade the firmware of the password is: admin. The password can contain from 0 to ENH900EXT. -
Page 64: Backup/Restore
ENH900EXT incorrectly, you can use the Reset Restore to Default: Click Reset button to restore the button in the Revert to Factory Default Settings section ENH900EXT to its factory default settings. to restore all the configurations of the ENH900EXT to the original default settings. - Page 65 If extreme problems occur, or if you the user settings you would like to the device’s memory have set the ENH900EXT incorrectly, you can push the for the default settings. Reset button to revert all the configurations of the...
-
Page 66: Log
System Log Remote Log The ENH900EXT automatically logs (records) events This page allows you to setup the Remote Log functions of possible interest in its internal memory. To view the for the ENH900EXT. logged information, click the Log link under the System Manager menu. -
Page 67: Logout/Reset
Logout Reset Click Logout in Management menu to logout. In some circumstances, it may be required to force the device to reboot. Click on Reset to reboot the ENH900EXT. -
Page 68: Appendix
Appendix... -
Page 69: Fcc Interference Statement
Appendix A Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 70: Ce Interference Statement
Appendix B - CE Interference Statement Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: •... - Page 71 This device is a 5GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries, except in France and Italy where restrictive use applies. In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services.
- Page 72 Français [French] Par la présente [nom du fabricant] déclare que l’appareil [type d’appareil] est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italiano [Italian] Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
-
Page 73: Ic Interference Statement
Appendix C - IC Interference Statement Industry Canada statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à... -
Page 74: Professional Installation Instruction
Appendix D - Professional Installation Instruction Installation Personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. Installation Location The product shall be installed at a location where the radiating antenna can be kept 38cm from nearby person in normal operation condition to meet regulatory RF exposure requirement. - Page 75 Instructions d’installation professionnelle Installation CCe produit est destine a un usage specifique et doit etre installe par un personnel qualifie maitrisant les radiofrequences et les regles s’y rapportant. L’installation et les reglages ne doivent pas etre modifies par l’utilisateur final.final. Emplacement d’installation En usage normal, afin de respecter les exigences reglementaires concernant l’...
-
Page 76: Detachable Antenna Usage
(e.i.r.p.) is not more than that necessary for successful communication. This radio transmitter (IC: 10103A-ENH900EXTA / Model: ENH900EXT) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
