Interference Detection - Humanscale TouchPoint T7 User Manual

3.1 INTERFERENCE DETECTION

From the LINAK User Manual:
Anti-collision
The anti-collision function is a new option for the standard CBD4/CBD5 advanced/control box software version 1.66 and later.
A system with anti-collision can limit material damages on a desk if a collision with a solid object should occur.
Situations in which the anti-collision function does not work
There are situations in which the anti-collision function will not be activated.
These situations are:
• If the collision happens during the initialization phase
• If the collision happens within the first 1,000 msec or after the control button has been released
• If the collision happens between the floor and the table and the load on the desk plus the weight of the legs is lower
than 40 kg
• If the collision happens over too long a time, e.g., if the collision is with a soft object.
24
