Wiring the Hardscape Sub 4 :
Cut the blue/white and yellow/green wires. Connect the
yellow (4 + input) wire & the blue (4 - input) wire to the
positive and negative output from the 4 amp.
4 OHM AMPLIFIER
4 - INPUT
4 + INPUT
To 70V Speakers
4
OUTDOOR SPEAKERS and SUBWOOFERS PRODUCT WARRANTY
All outdoor speakers and subwoofers have a limited 5 year warranty. This warranty includes lifetime parts and repair
labor on all components. The warranty extends only to the original purchaser of the product and not to any
subsequent owner. TRUAUDIO's obligation under these warranties is limited to repairing or replacing any
component found defective in material or workmanship under normal conditions of use with an equal and/or current
product. These warranties shall not apply to products which have been abused, modified, or disassembled.
Products to be repaired or returned under this warranty must be returned to the factory through an authorized
TruAudio dealer with all transportation and insurance charges prepaid.
I t is the pol i cy of T RU AUD IO to co ntin uo us ly i ncor po ra te im provements i nto o ur products. A ll sp ecif icat i ons are
s u b je ct t o c hange w it hout n otic e. If yo u h a ve a ny q ue sti on s reg ardin g thi s o r a ny othe r TRUAU DIO pro duct s,
pl e a se v i si t ww w. TruAudi o.c om or co nta ct u s:
O ffic e: 1 -8 88- 858- 1555, Monday -Friday 7 am - 6 pm MS T.
E mai l: Cust om er Ser v ic e@tr uaudio.com
HS-SUB-12
Specifications
Frequency Response:
Cabinet Dimensions:
SoundVision Technologies dba
Tru Au di o
198 N Ol d H i g hw ay 91
H ur ri c an e, U T 84 73 7 U SA
Speaker Type: Outdoor Hardscape subwoofer
12" injected polypropylene
Woofer:
Impedance: 4 or 70V
Power (4 ): 250W
200W
Power (70V):
28 - 150 Hz (+/- 3dB)
Sensitivity: 90dB
15.6" (396mm) W,
15.6" (396mm) D,
16.5" (420mm) H,
