Kvik PO802,080 Assembly Manual page 2

K10145 ,**
Side
2 pcs
K12155
Shelf
2 pcs
L08040, (355-359)
Door
2 pcs
BP00417
Mounting plate
4 pcs
Bumper
Screw flh
7x1,5 mm
3,5x15 mm
2 pcs
6 pcs
27-08-2018 0a /
Check out easy
mounting of your kitchen
DO80,080,000 / 176
Suspension list
ID21570
ID21570
Push open
2 pcs
BP00418
Hinge 107 degrees
4 pcs
BP00205-BP00250-BP11400
Screw flh
3,5x45 mm
8 pcs
K11165 ,**
Base top
2 pcs
K13355
1 pcs
Euro screw
6,3x11 mm
4 pcs
Shelf support
5x7 mm Plast
8 pcs
PO802,080
K13180
Back panel
1 pcs
K13358
Suspension list
1 pcs
Angle
45x55x30x2 mm
2 pcs
PZ11400
Washer
2 pcs
2 / 9
