Bakers Pride Y-600-DSP Specifications

SUPER DECK
Y-DSP SERIES
BAKERS
GAS DISPLAY OVENS
PRIDE
Model Y-602-DSP
with optional stone finish
SPECIFICATIONS
BAKERS PRIDE Y-DSP Display Ovens are ideal for display cooking
and exhibition kitchens. These ovens are designed and engineered
to be "built-in" behind brick, stone or tile applied directly to ovens
exterior or finished and trimmed in brass, copper, stainless or
powder-coated trim.
Ovens may be stacked two high. Oven exteriors are all heavy-
gauge steel and are fully insulated up to 5" (127mm) thick for
cooler outer temperatures and consistent interior temperatures.
Interior oven frame is constructed of 1/4" (6mm) heavy-duty angle
iron frame, completely welded to form a single, unitized section.
The oven body and lining are then welded to the framework.
Oven interiors are manufactured of high-heat resistant 16-gauge
aluminized steel. Doors are fully insulated, spring balanced with
natural black finish and custom wood handles.
Lintel plates support the masonry or tile for ease of installation.
Standard features include dome top plus front and side skirts.
All models feature independent, operator-controlled top & bottom
heat control dampers and micro slides for perfectly balanced
results.
Y Series features a 300°-650° F (149°-343°C)
8" (203mm) interior deck height with
stone decks (steel decks optional) and are supported by a 1/4"
(6mm) angle iron frame.
Combination gas control incorporates a manual gas valve, pilot
safety and pressure regulator. Easily removable, slide-out, heavy-
duty flame diverters distribute the burner flame uniformly in the
burner chamber. A 3/4" (19mm) NPT gas connection is located on
the left side and left rear of oven - operator/installer may choose.
Heavy-duty, 7-gauge hot rolled steel legs are standard and finished
with durable Bakertone.
2 Year limited part and labor warranty standard.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
BAKERS
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
PRIDE
www.bakerspride.com
throttling thermostat,
1 1/2" (38mm) thick hearth
Job ____________
GAS DECK OVENS
q
Model Y-600-DSP Single
q
Model Y-602-DSP Double
q
Model Y-800-DSP Single
q
Model Y-802-DSP Double
STANDARD FEATURES
q Y Series @ 120,000 BTUH per deck, natural or LP gas
300°-650° F (149°-343°C) throttling thermostat
q
q Top & bottom heat control dampers & micro-slides
q Combination gas controls with valve, regulator & pilot safety
Heavy-duty, slide-out flame diverters
q
q 8" (203mm) interior deck heights with 1 1/2" (38mm) thick
hearth stone decks
Black powder coated doors with custom hardwood handles or
q
stainless doors with tubular steel handles
q Front or side mounted controls with large, hinged access
cover door in black powder coat or stainless steel
q Dome top - removable for field installations
q Front & side skirts
q Aluminized steel interiors
Spring balanced, fully insulated doors
q
q Rear gas connections
q 7-Gauge legs
Fully insulated throughout
q
q 2 Year limited part and labor warranty
OPTIONS & ACCESSORIES
Side-mounted controls
q
q Steel decks in lieu of hearth stone decks
q 150°-550° F (65°-288°C) thermostat
Automatic oven starter
q
q Draft flue for direct vent (not available on CE units)
q Fire brick hearth decks (Y-600/602 only)
Without dome and/or without skirts
q
q Set of 4 casters - two with locks - not for use with skirts
CERTIFICATIONS
®
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
Item # ___________
G
CERTIFIED
