- Page 1 Manual Buck-Boost DC-DC converter 25A and 50A...
-
Page 3: Table Of Contents
Contents 1. General Description 1.1 Applications 1.2 General features 2. Connections 3. LED indicators 4. Engine running detection 5. Charge current limiter 6. Freely programmable (engine running detection and connected users) 7. Wiring diagram 8. ConverterMonitor PC application 9. Technical specifications 1. -
Page 4: Connections
2. Connections The converter has three M8 bolt connectors for in- and output power, a two wire connector that can be used as inputs or outputs and an USB connector to connect to a computer to configure the device. Converter input (dynamo/starting battery) GROUND (chassis) Converter output (additional battery) Pin 1... -
Page 5: Engine Running Detection
4. Engine running detection The converter has a unique engine running detection system. This prevents the converter from discharging the starter battery if no power is being supplied by the alternator. The converter turns ON when the engine is running and the input voltage exceeds the pre-set voltage. 5. -
Page 6: Convertermonitor Pc Application
8. ConverterMonitor PC application With the ConverterMonitor pc program it is possible to monitor the live values of the converter: Input voltage Output voltage and current Temperature It is also possible to configure the converter by setting various parameters: Output voltage Maximum input and output current Maximum temperature Under voltage threshold... -
Page 7: Technical Specifications
Technical specifications Buck-Boost DC-DC Converter Input voltage range 7-35V Under voltage threshold Output voltage range 2-30V Maximum charge current 12V : 25A 24V : 15A 12V : 50A 24V : 25A Power consumption Converter off, LEDs off (power save mode) On/off input (pin 1, purple wire) ‘On’... - Page 8 Distributor: Serial number: Version : 01 Date : 21 March, 2016 Victron Energy B.V. De Paal 35 | 1351 JG Almere PO Box 50016 | 1305 AA Almere | The Netherlands General phone +31 (0)36 535 97 00 Customer support desk...
