CONCEPT IQ. Installation & Programming Manual.
Contents
Control Module Parts List ..............................................................................................................1
Specifications .................................................................................................................................1
Installation Procedure ....................................................................................................................2
Connection Details. Zone Inputs (Detectors), Tamper switch and Fuses ................................ 3
Mode 3 Telephone line connection ..............................................................................................3
Connection Details. Power, Warning devices & LAN ................................................................. 4
Control Module Parts List
- Control Module PCB mounted in metal enclosure.
- User Manual.
- Installation Manual. (This document)
- Installation Kit containing:
- 4 x Pan Head Self-tapping screws 4x6mm. Used to secure the enclosure cover.
- 5 x plastic "D" bungs. Must be fitted to all unused cable entry cutouts in the cover.
- Telecom Line cord. (Note: Non-standard configuration. Only suitable for use with this product)
- 10 x 3k3 End-of-line resistors. (orange-orange-black-brown-brown) Used for Single EOL / Dual EOL / Zone Doubling.
- 10 x 6k8 End-of-line resistors. (blue-grey-black-brown-brown) Used for Dual EOL or Zone Doubling.
- 10 x 1k End-of-line resistors. (brown-black-black-brown-brown) Used for Zone Doubling.
- Tamper switch.
- Tamper switch bracket.
- 2 x 6 Way plug-on screw terminals. (Only for PCBs that do not have fixed terminal blocks fitted)
- 1 x 3 Way plug-on screw terminals. (Only for PCBs that do not have fixed terminal blocks fitted)
- 5 x 2 Way plug-on screw terminals. (Only for PCBs that do not have fixed terminal blocks fitted)
- 2 x 6.3mm Tamper switch connectors.
- Battery connection lead, 220mm, pre-assembled.
- 1 x 1 Amp M205 (20mm) Fuse. (Spare)
Electrical Specifications
Power Supply I/P: Plug pack Mains Supply:
Plug pack Output:
PCB AC Input Voltage:
Battery Capacity:
DC Operating Voltage (Batt I/P)
Battery Input Fuse:
Power Supply O/P: Current:
Fuse Protection:
Auxiliary Outputs: OUT1 (Strobe) / OUT2
Siren Output (SPK): Maximum Load:
NOTES: 1) ALWAYS REPLACE FUSES WITH THE SAME FUSE TYPE AND VALUE!
2) See data supplied with detectors and output devices for current consumption.
Mechanical Specifications
Dimensions: Height: 260 mm.
Weight: 4.2 kg. (Cabinet & cover, PCB and 7AH battery)
Environmental Specifications
Continuous Operating Temperature
Storage Temperature
Relative Humidity (Non condensing)
© 2001. Inner Range Pty. Ltd.
Control Module. 995501
240V AC -10% / +10%. 50 Hertz.
16V AC. 1.0 Amperes.
16V AC.
12V. 7AH. Sealed Lead Acid Battery.
9.5 to 14 V DC. (Low Battery alarm activated at 11.2V +/- 0.3V)
1 Ampere.
Total combined current required by devices connected to
"DET+" and "LAN+" must not exceed 600 milliAmps.
1 Ampere. (DET+ and LAN+)
Max. switched current = 200mA per Auxiliary. (Open Collector)
8 Ohms. (i.e. 1 x 8 Ohm Speaker only. Additional speakers must
not be connected in parallel)
Width: 265 mm.
0 to +50 °C
-20 to +70 °C
15 to 85 %
Control Module. Version 1.02
Depth: 80 mm.
Plug pack = 0.6kg
p3
Part No: 635501
