WHAT'S INCLUDED • 5ft HDMI Cable • Digital Wireless HD Transmitter • 2x Screws/Screw Anchors • Digital Wireless HD Receiver • 1 Year Warranty • 1 External IR Receiver • Lifetime Customer Support • 1 External IR Emitter • 2x 100-240V AC Power Adapters OVERVIEW HDMI IN HDMI OUT...
INSTALLATION RECEIVER RECEIVER RECEIVER TRANSMITTER DEVICE TRANSMITTER HDMI 1 HDMI 2 HDMI IN HDMI OUT IR OUT TRANSMITTER DEVICE HDMI 1 HDMI 2 HDMI IN HDMI OUT IR OUT TOP VIEW DEVICE 30° 30° 5-10cm TOP VIEW HDTV DEVICE DEVICE TRANSMITTER RECEIVER 30°...
Page 5
HDMI 1 HDMI 2 HDMI IN HDMI OUT IR OUT TRANSMITTER DEVICE IR EXTENDER SETUP HDMI 1 HDMI 2 HDMI IN HDMI OUT IR OUT TOP VIEW DEVICE 30° 30° 5-10cm HDTV DEVICE TRANSMITTER TOP VIEW RECEIVER DEVICE IR sensor must be in front of IR window of device.
Page 6
SPLASH SCREENS CONNECTING SCREEN: Receiver is searching for Transmitter. Please wait. TROUBLESHOOTING SCREEN: Receiver has not yet found Transmitter, please check the displayed tips to ensure connection. PAIRING MODE SCREEN: Receiver has entered manual pairing mode.
RECEIVER LED BEHAVIOR LED Behavior WHEN CONNECTED: LED will remain solid white permanently WHEN CONNECTED: WHEN NOT CONNECTED: LED will remain solid white permanently LED will turn on for 1 second, WHEN NOT CONNECTED: then off for 3 seconds and LED will turn on for 1 second, then off for 3 seconds and repeat repeat...
Page 8
3. Plug the external IR receiver into the IR IN socket on the back of the receiver HDMI 1 HDMI 2 4. Place the IR remote receiver bubble in front of the TV HDTV 30° 30° 5-10cm RECEIVER...
3 seconds and repeat Pairing Button: 3. Insert two screws into the anchors. 4. Place WS55 main holes over the To use to pair with additional receivers or to manually repair included Transmitter and Leave 1/8” length for mounting the protruding screws and slide down into Receiver.
Transmitter that is connected to your HD device. Power LED Make sure the power cable is connected to a known good outlet. Ensure it is firmly connected to the WS55. Always used the provided power adapter. Transmitter Check the HD device is powered on.
Page 11
Thank you for your purchase of the Nyrius WS55. If you require any assistance please review the below Frequently Asked Questions. 1. WHAT DOES THE STATUS OF THE LED'S MEAN? SOLID WHITE LINKED Transmitter/Receiver is linked. FLASHING WHITE SEARCHING Transmitter/Receiver not in range.
Page 12
5. THE WS55 APPEARS WARM AFTER PROLONGED USE. To transmit 3D or Full HD content wirelessly, the WS55 must process a large amount of data. Due to this, the unit may run at warmer temperatures than other electronic devices. We have designed the housing to provide proper ventilation to the unit as well as have designed the electronic components to withstand temperatures up to 80°C.
SPECIFICATIONS SUPPORTED VIDEO RESOLUTION 1080p, 1080i, 720p, 576p, 480p 3D COMPATIBLE AUDIO FORMATS PCM 2CH, Dolby 5.1 PORTS & INTERFACES Transmitter: HDMI input, HDMI Loop Through (Output), Micro USB (for power), 2.5mm Jack (for IR Emitter) Receiver: HDMI Output, Micro USB (for power), 3.5mm Jack (for IR Emitter) WIRELESS RANGE 40ft (clear line of sight)
FCC STATEMENT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. WARNING: This equipment has been tested and is found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
SAFETY INFORMATION Read all instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
