DT301A
BASICOPERATIONGUIDE
ENGLISH
INTRODUCTION
Thank you for acquiring the latest addition to DT Research's line of tablets — the DT301A.
Featuring a slim yet robust enclosure, the DT301A with 10.1" capacitive touch display is powered
by the Intel® processor, offering optimal combinations of performance and power savings. The
DT301A is available with Microsoft operating system. The operating system features web
browser, client/ server computing software, media player, accessories, and applications support.
PACKAGE CONTENTS
• One DT301A with Battery Pack and Handstrap
•Capacitive Touch Stylus and Lanyard
• AC‐DC Power Adapter with Power Cord
• Basic Operation Guide
Advertisement
Table of Contents
Related Manuals for DT Research DT301A
Summary of Contents for DT Research DT301A
- Page 1 DT301A BASICOPERATIONGUIDE ENGLISH INTRODUCTION Thank you for acquiring the latest addition to DT Research’s line of tablets — the DT301A. Featuring a slim yet robust enclosure, the DT301A with 10.1” capacitive touch display is powered by the Intel® processor, offering optimal combinations of performance and power savings. The DT301A is available with Microsoft operating system. The operating system features web browser, client/ server computing software, media player, accessories, and applications support. PACKAGE CONTENTS • One DT301A with Battery Pack and Handstrap •Capacitive Touch Stylus and Lanyard • AC‐DC Power Adapter with Power Cord • Basic Operation Guide ...
- Page 2 DT301A DT301A: Input/ Output Ports Button Functions A Headphone Jack BUTTON ACTION B USB 3.0 Port 1 power button C DC Power Input 2 programmable button Battery Latch D GNSS module 3 • Push the switch to unlock the latch, than slide the latch to left to remove the battery. E Back Camera (optional) F Long Range Tansmitter module ...
- Page 3 Precautions • Always exercise care when operating and handling the DT301A. • Do NOT apply excessive pressure to the display screen. • Avoid prolonged exposure of the display panel to any strong heat source. Wherever possible, the DT301A should face away from direct light to reduce glare. • If the AC‐DC power adapter is used to recharge or power the tablet, do NOT use any AC‐DC adapter other than the one provided or acquired from the manufacturer or its partners. • In the unlikely event that smoke, abnormal noise, or strange odor is present, immediately power off the DT301A and disconnect all power sources. Report the problem to your device provider immediately. • Never attempt to disassemble the DT301A, as this will void the warranty. Basic Features The DT301A wireless tablet integrates a bright display, one USB port, and embedded networking elements such as wireless LAN and Bluetooth, 4G LTE and Long Range Tansmitter module. The DT301A is complemented by a suite of accessories, including battery expansion, charging cradles, and battery charger kit, for a comprehensive user experience. A DT301A typically integrates an 802.11ac wireless LAN (WLAN) adapter that may connect to other wireless devices or access points. If your DT301A does not come with such a network adapter, please consult your device provider to establish the desired network connectivity. ...
- Page 4 DT301A OPERATION Internal Battery Warning The Internal battery pack should only be replaced by an authorized DT Research service representative. Please contact your product and/or service provider for internal battery replacement service. Powering ON and OFF To activate the DT301A, push and quickly release the Power Button. The display will come on in a few seconds. To put the DT301A in Standby mode, push and quickly release the Power Button. To turn the DT301A off for extended storage, power off safely using any software function that “shuts down computer” provided in the software operating system. NOTE: The battery packs shipped with your tablet may be low in power—please use the AC‐DC adapter with the DT301A when setting up for the first time to fully charge the internal battery pack. You may charge the external battery pack with it attached to the DT301A, or with the optional external battery charger kit. NOTE: When the battery pack(s) is (are) charging, the blue‐colored Battery LED should blink slowly. If plugging in the AC‐DC adapter does not trigger this blinking activity and the LED stays dark, the battery pack(s) may have been drained substantially. Try unplugging/ replugging the AC‐DC adapter to the DT301A a few times to activate the charging process. NOTE: To conserve power, use (push and quick release) the Power Button to put in “Standby” mode while not in use. Pushing briefly on the same button will wake up the system within seconds. NOTE: Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the tablet—this form of hardware shutdown is intended to be a means of recovery from lockups, and not as normal operation. ...
-
Page 5: Wireless Networking
DT301A Start Up If the power up (from Standby or otherwise) is successful, the appropriate interface will be displayed after a launch sequence of several seconds. The wireless LAN connection may take 10‐15 seconds to be established. Configuring the Mobile Tablet TheDT301Amay be configured using the utilities and methods dictated by the software operating system. The DT301Ashould be configurable for various properties such as user profiles, network features, and several system elements. Wireless Networking Wireless LAN The DT301A is often delivered with an embedded(user‐inaccessible) 802.11ac WLAN adapter equipped with a hidden custom antenna. • Through the support of typical WLAN adapters, theDT301Ashould be able to detect all 802.11 access points in the vicinity for you to select the access point of your choice for connection. • The SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT301A and the access points have to match. The SSID is case‐sensitive and it is recommended that you enable WEP/WPA/WPA2 encryption (or advanced alternatives) for secure access. •When WEP/WPA/WPA2 is enabled, you may need to consult your network administrator or your networking equipment literature to properly configure associated settings such as Authentication mode, etc. •Refer to the access point operating manuals for setting up the 802.11 access points. ENGLISH DT301A ... - Page 6 Bluetooth The Bluetooth configuration application is enabled from the System Tray or from the Windows Mobility Center. Follow the instructions and options provided within the application to configure and invoke Bluetooth connectivity with the corresponding peripherals. Long Range Tansmitter Long Range Tansmitter, the CIRRONET WIT2410, provides a transmission range of approximately to 100 meters, supporting point‐to‐point or multipoint applications. It ensures maximum resistance to noise and multipath fading and robustness in the presence of interfering signals, while operation in the 2.4GHz ISM band allows license‐free use and worldwide compliance. A simple serial interface supports asynchronous data up to 230400 bps. An on‐board 3 KB buffer and an error‐correcting over‐the‐air protocol provide smooth data flow and simplify the task of integration with existing applications. USING THE MOBILE TABLET Peripherals Support Through its USB port, the DT301A supports awide range of USB‐based peripherals. These peripherals are applicable for software installation, applications storage, data storage, and system software recovery and updates. Remote Management Depending on software configuration, the DT301Acan be centrally managed for asset monitoring and for software control. Please consult your device provider. For More Support Users can download the Tablet Modules Basic Operation Guides from the DT Research website. ...
- Page 7 DT301A DT301A installation The major application of DT301A is for Architecture measurement that is utilized the Long Range Tansmitter. The DT301A installation and operation, please see the below photos, is erected on the tripod. The distance is exceed 20cm between DT301A mobile tablet and the body of operator that ensure the precision and accuracy of measurement. ENGLISH DT301A ...
-
Page 8: Specifications
Specifications: DT301A Item System CPU Intel® 6 Generation Core™ i7, 2.6GHz RAM 8GB Storage 128GB flash Operating System Microsoft® Windows®7 Professional or Windows®10 IoT Enterprise Display 10.1” LED‐backlight screen with multi touch capacitive touch Display Resolution 1920 x 1200 Network Interface Wi‐Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.1 LE Mobile Broadband provides LTE, WCDMA, CDMA U‐blox M8 GNSS module with concurrent reception of GPS and GLONASS. GNSS Module Long Range Tansmitter 2.4GHz to 2.483GHz, FCC Part 15.247 and ETSI 300328 rules, license free Control Switch and 1 power button, 1 Wifi switch and 3 programmable buttons Buttons ... -
Page 9: Fcc Warning
FCC Warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ... -
Page 10: Radio Frequency (Rf) Exposure Information
Canada, ISEDC Notices This device complies with ISEDC’s licence‐exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Canada, avisd'ISEDC Le présentappareilestconforme aux CNR d'ISEDCapplicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. Users should also be advised that high‐power radars are allocated as primary users (i.e. priority users) of the bands 5250‐5350 MHz and 5470‐5725 MHz and that these radars could cause interference and/or damage to LE‐LAN devices. 5GHz WifiBand 1 should indoor use only. Devraientégalementêtreinformés les utilisateurs que les radars à haute puissance sontdésignéscommeutilisateursprincipaux (c.‐à‐utilisateursprioritaires) des bandes 5250‐5350 MHz et 5470‐5725 MHz et que ces radars pourraientprovoquer des interférences et / ouendommager les appareils LE‐LAN.Le Wifi 5 GHz ne doitêtreutiliséqu'àl'intérieur. Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the ISEDC radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the ISEDC Specific Absorption Rate (“SAR”) limits when operated in portable exposure conditions. When the device installed for distance measurement, please make sure the device be installed and ...
