Initial Setup Guide
DRX-3.2
AV RECEIVER
SN 29403393
＊1
＊2
＊3
＊ 1: 22° to 30°, ＊ 2: 90° to 110°, ＊ 3: 135° to 150°
7.1 ch System
1,2
Front Speakers
3
Center Speaker
4,5
Surround Speakers
6
Powered Subwoofer
7,8
Surround Back Speakers
Refer to the instruction manual
available on our website to install and
connect speaker systems other than
7.1 ch.
http://integraworldwide.com/manual/drx32/top.pdf
Install & Connections
1
H1803-0
* 2 9 4 0 3 3 9 3 *
3
1/2˝
(12 mm)
1
a
2
4-16Ω
3
2
b
a Speaker cable, b Subwoofer cable
Refer to the instruction manual available on our website to install and
connect speaker systems other than 7.1 ch.
http://integraworldwide.com/manual/drx32/top.pdf
1
2
3
Advertisement
Table of Contents
Related Manuals for Integra DRX-3.2
Summary of Contents for Integra DRX-3.2
- Page 1 Initial Setup Guide Install & Connections DRX-3.2 AV RECEIVER SN 29403393 H1803-0 * 2 9 4 0 3 3 9 3 * ＊1 ＊2 ＊3 ＊ 1: 22° to 30°, ＊ 2: 90° to 110°, ＊ 3: 135° to 150°...
- Page 2 1 Used during Initial Setup. c HDMI cable 2 d Digital optical cable DIGITAL Connect speakers with 4 Ω to 16 Ω impedance. If any of the connected speakers have an impedance of 4 Ω or more to less than 6 Ω, after completing "Initial OPTICAL OUT Setup", you need to make some settings in the Setup menu.
