- Page 1 Operating instructions KBD-USB-* keyboards KBD-USB-TB50-* KBD-USB-M-* KBD-USB-P-* KBD-USB-J-* R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln Operating Instructions Version: 01.00.02 Issue date: 24.08.2018...
-
Page 2: Disclaimer
Trademarks The terms and names used in this document are registered trademarks and / or products of the companies in question. Copyright © 2018 R. STAHL HMI Systems GmbH. Subject to alterations. Page 2 of 16 R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018... -
Page 3: Specific Markings
! Warnings Caution ! In ambient temperatures exceeding +45 °C the surface of the devices may heat up. Caution when touching ! R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018 Page 3 of 16... -
Page 4: Table Of Contents
Safety information for operation Special conditions Mechanical dimensions Cut-out Connections Maintenance Troubleshooting 12.1 Repairs / hazardous substances Disposal 13.1 RoHS directive 2011/65/EC Declaration of EC conformity Release Notes Page 4 of 16 R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018... -
Page 5: Preface
The touchpad uses resistive technology and can therefore be operated with a touch pen or with gloved fingers. The keyboards can be mounted inside a front panel or a desktop housing. R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018 Page 5 of 16... -
Page 6: Type Allocation
Dimensions (W x H x D) [mm] / [ft] 581 x 186 x 50 / [1.91] x [0.61] x [0.16] Weight [kg] / [lbs] 3.0 / [6.6] Page 6 of 16 R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018... -
Page 7: Conformity To Standards
KBD-USB-aa-DE Lanugage: German (QWERTZ) KBD-USB-aa-US Language: American (QUERTY) KBD-USB-aa-FR Language: French (AZERTY) KBD-USB-aa-FR-BE Language: French, Belgian version (AZERTY) KBD-USB-aa-CH Lanugage: German, Swiss layout KBD-USB-aa-ES Language: Spanish R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018 Page 7 of 16... -
Page 8: Safety Information
National safety and accident prevention rules apply. Use the device for its intended purpose only. No changes to the device are permitted. The enclosure may only be opened by R. STAHL HMI Systems GmbH. The first four digits of the serial number on the type plate stand for the year of manufacture. -
Page 9: Mechanical Dimensions
Operating Instructions KBDi Keyboards Mechanical dimensions Mechanical dimensions Dimensions in mm, [inch] Cut-out R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018 Page 9 of 16... -
Page 10: Connections
Trackball X73, mouse X94, touchpad X95, joystick X96: Cable Colour Signal name Definition + UB Power supply +UB White Data cable D- Green Data cable D+ Black Power supply GND Page 10 of 16 R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018... -
Page 11: Maintenance
– if requested – have been authorized by the manufacturer. 12.1 Repairs / hazardous substances An error description must be enclosed with any units returned to R. STAHL HMI Systems GmbH for repairs. Remove all material residues. Please pay particular attention to the seal grooves and slits where material residues may be lodged. -
Page 12: Declaration Of Ec Conformity
Operating Instructions KBDi Keyboards Declaration of EC conformity 14 Declaration of EC conformity Page 12 of 16 R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018... -
Page 13: Release Notes
Addition of RoHS directive in "Conformity to standards" Adaption of section "Disposal" according to the current WEEE directive Deletion of chapter "Front panel resistance" Formal changes R. STAHL HMI Systems GmbH / OI_KBD_USB_en_V_01_00_02.doc / 24.08.2018 Page 13 of 16... - Page 16 R. STAHL HMI Systems GmbH Adolf-Grimme-Allee 8 D 50829 Köln Phone: (switchboard) +49 (0) 221 76 806 - 1000 (hotline) - 5000 Fax: - 4100 E-mail: (switchboard) office@stahl-hmi.de (hotline) support@stahl-hmi.de www.r-stahl.com www.stahl-hmi.de...
