Riding Mower; Schematic - Poulan Pro PP11G30 Repair Parts Manual

CORTADORA DE CÉSPED NUM. DE MODELO PP11G30 (96022002900)
POULAN PRO ENGINE (352 CC)
1
2 3
6
13
11
12
20
21
19
28
29
27
26
32 33
PRODUCTO NO. 960 22 00-29
1A
4 5
8
9
14
15
16
23
22
24
30
31
30

RIDING MOWER

SCHEMATIC

SCH24
7
10
17
18
25
POSITION
RUN/OVERRIDE
MODEL NUMBER
BATTERY
R E D
FUSE
S
B
M
G A1
WHITE
L
A2
BLACK
BLACK
REVERSE SWITCH
NOT IN REVERSE
BLACK
BLACK/WHITE
FUEL SHUT-OFF
SOLENOID
BLUE
(IF EQUIPPED)
RED
IGNITION SWITCH
WIRING INSULATED CLIPS
CIRCUIT "MAKE"
NOTE: IF WIRING INSULATED CLIPS
OFF M+G+A1
WERE REMOVED FOR SERVICING OF
B+A1
UNIT, THEY SHOULD BE RE-INSTALLED
TO PROPERLY SECURE YOUR WIRING.
RUN B+A1 L+A2
START B + S + A1
3
PP11G30 (96022002900)
PRODUCT NUMBER 960 22 00-29
STARTER
M
RED
CLUTCH / BRAKE
ATTACHMENT CLUTCH
(PEDAL UP)
(CLUTCH OFF)
BLACK
SEAT SWITCH
(NOT OCCUPIED)
BLACK
GRAY
GRAY
SHORTING CONNECTOR
BLACK
SPARK PLUGS
IGNITION
GAP
UNIT
(2 PLUGS
ON TWIN CYL. ENGINES)
CHARGING SYSTEM OUTPUT
28 VOLTS AC MIN. @ 3600 RPM
3 AMP DC @ 3600 RPM
(CHARGING SYSTEM DISCONNECTED)
STATOR
DIODE
REMOVABLE
CONNECTIONS
NON-REMOVABLE
CONNECTIONS
