Decals - Poulan Pro PP11G30 Repair Parts Manual

RIDING MOWER MODEL NUMBER

DECALS

3
4
KEY PART
NO. NO.
1 591 44 58-01
3 581 57 93-01
4 532 44 14-97
6 582 67 71-01
7 581 72 43-01
8 584 90 46-01
- - 115 92 06-49
- - 115 92 07-32
- - 115 92 08-49
- - 115 92 09-32
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
PP11G30 (96022002900)
PRODUCT NUMBER 960 22 00-29
6
8
1
7
DESCRIPTION
DECAL, LRV DECK
DECAL, WARNING
DECAL, V-BELT SCH
DECAL, STRWHL
DECAL, DECK NO STEP
DECAL, DECK/DEFLECT. WARNING
MANUAL, OPERATOR'S, ENGLISH/SPANISH
MANUAL, OPERATOR'S FRENCH
MANUAL, REPAIR PARTS, ENGLISH/SPANISH
MANUAL REPAIR PARTS, FRENCH
