8 March, 2016
ASEK-1363-40-41-T-KIT Quick Guide
The ASEK-1363-40-41-T-KIT as described below is for the purpose of evaluating
certain Allegro devices in the KT package with an ASEK20.
At the time of release, this board supports A1340, A1341 and A1363 KT devices.
Note: This board does not support A1367.
ASEK-1363-40-41-T-KIT Bill of Materials
ASEK-20 Kit (Part # 85-0540-600)
o ASEK-20 Chassis with main Motherboard inside (85-0540-004)
o USB Communications Cable
o DC Power Supply/Cable with AC Outlet Adapters
o Proto Board ( Part # 85-0540-103)
o Ribbon Cable (Part # 85-0540-300)
ASEK-1363-40-41-T:
o ASEK-20 4 Lead KT Daughterboard (Part #: 85-0614-003 Rev2)
Figure 1. ASEK-20-T-KIT
ASEK-20KT-T-KIT
Figure 2. ASEK-20 4 Lead KT Daughterboard
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Allegro ASEK-1363-40-41-T-KIT
Summary of Contents for Allegro ASEK-1363-40-41-T-KIT
- Page 1 8 March, 2016 ASEK-1363-40-41-T-KIT Quick Guide The ASEK-1363-40-41-T-KIT as described below is for the purpose of evaluating certain Allegro devices in the KT package with an ASEK20. At the time of release, this board supports A1340, A1341 and A1363 KT devices.
- Page 2 Necessary test points are indicated below. Device GND Device Output Pin 1 location Figure 3. Setup of ASEK-1363-40-41-T-KIT Software for ASEK-1363-40-41-T-KIT In order to download the software for your specific Allegro KT Package device, register at the software portal below: https://registration.allegromicro.com/login...
