Passive Infrared (PIR) Accessory Covers
Installation Instructions
TEC-3-PIR, TEC-6-PIR, TEC-6H-PIR, and TEC-7-PIR
Applications
The Passive Infrared (PIR) Accessory Covers with
embedded PIR motion detectors are specifically
designed to work with compatible Johnson Controls®
TEC and T60x Series Equipment Controllers. These
accessory covers are designed to retrofit previously
installed controllers, or to serve as replacement covers.
When equipped with a PIR Accessory Cover, the
controller provides advanced active occupancy logic,
which automatically switches occupancy levels from
Occupied to Unoccupied or Standby as required by the
presence of local activity. This added occupancy
sensing capability provides energy savings during
occupied hours without sacrificing occupant comfort.
A PIR Accessory Cover is suited for the following
applications:
•
lodging Fan Coil Unit (FCU) applications
•
TEC Zoning Control System zones
•
conference rooms
•
classroom units
•
any commercial offices that have random
occupancy schedules during occupied hours, as
dictated by the function of the tenant
•
any controlled piece of HVAC equipment that may
yield energy savings with the introduction of a new
automatic standby level of occupancy
North American Emissions Compliance
United States
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area
may cause harmful interference, in which case the
users will be required to correct the interference at
their own expense.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Passive Infrared (PIR) Accessory Covers Installation Instructions
24- 9890- 870, Rev . E
Part No. 24-9890-870, Rev. E
Issued March 2016
1
