6/8 RIGHT/LEFT Button
9 USB Port
10 ESC Button

2.2 Specifications

1) Screen: 2.8" TFT 262K true color, 320*240dpi
2) Input voltage range: 9~18V
3) Operating current: <100mA@12V (Typical)
4) Power consumption: <1.2W (Typical)
5) Operating temperature: 32°F~122°F / 0°C~50°C
6) Storage temperature: -4°F~158°F / -20°C ~70°C @ RH60%
7) Outline dimension: 4.7'*3.2'*1.0' / 121*82*26 mm (L x W x H)
8) Weight : < 300g

2.3 Accessories

1) User's Manual -- Instructions on tool operations
2) USB cable -- Connect to a computer for upgrading online

2.4 Product Troubleshooting

Vehicle Linking Error
A communication error occurs if the scan tool fails to
communicate with the vehicle's ECU (Engine Control Unit). You
need to do the following to check up:
Multi-system Scanner Series User's Manual
Move cursor right or left for
selection; Or turn page up or
down when more than one page
is displayed.
Connects to computer to update
the Multi-system Scanner.
Returns to previous menu.
