2 Product Descriptions

2.1 Outline of Multi-system Scanner

9
1 Power Indicator
2 Cable with OBD II
Connector
3 LCD Display
4/7 UP/DOWN Button
5 OK Button
2
Multi-system Scanner Series User's Manual
10
8
7
5
6
Figure 2-1
1
Lights up when your tool is
powered on.
Connects the Multi-system
Scanner to the vehicle's Data Link
Connector (DLC).
Indicates test results.
Move cursor up or down for
selection.
Confirms a selection (or action)
from a menu list.
