Technical Specification

Product Name: SoundBlasterX Katana
Model Number: MF8245
Bluetooth® Version: Bluetooth 4.2
Operating Frequency: 2402 - 2480 MHz
Total power: 75W (RMS)

Energy Saving Information

Power consumption

- Standby/Off : < 0.5 W
- Networked Standby : < 3 W (Bluetooth)
Power Management
- Power consumption < 0.5W after 28 hours inactivity when all network ports are deactivated / disconnected
- Networked standby within 20 minutes inactivity (Bluetooth, USB, Optical)
Activation & deactivation of wireless network port(s)
- To activate, perform Bluetooth device pairing
- To deactivate, disconnect Bluetooth from external device providing the audio source

Power Adapter Information

Model Number: DYS602-220250W
Input: 100-240VAC 50/60Hz
Output: 22VDC 2.5A
Operating Temperature range: 0º C to 45º C
Supported Bluetooth profiles*:
A2DP (Wireless Stereo Bluetooth), AVRCP (Bluetooth Remote Control)
Supported Codec: SBC, AAC
Operating Range: Up to 10 meters, measured in open space.
RF Output Power: < 4 dBm
Walls and structures may affect range of device.
Supports USB flash drives up to 128GB in FAT16/FAT32/exFAT format
Supported audio formats: MP3, WMA, FLAC and WAV (16 bit 48Khz PCM)
Support Mp3 and WMA up to 320kbps.
Does not support WMA Pro / Lossless
Support FLAC up to 1.3Mbps.
Support USB Audio up to 24 bit / 96 Khz
Support Optical Input up to 24 bit / 96 Khz, Dolby Digital
PC App Compatible with Windows 7/8/8.1/10
Note: Compliance markings are located on the bottom of this product.
< 3 W (USB)
< 3 W (Optical)
< 3 W (all network ports activated)
