Summary of Contents for elero Protero-868
- Page 1 Protero-868 289600006 | 289610006 289600906 | 289610906 0682 Operating instructions (translation) Keep the operating instructions in a safe place! 181227306_EN_1014...
- Page 2 Translation from the original German version. All other documents in different languages are translations of the original version. All rights reserved in the event of registration of patents, working models or design patents. 2 | EN elero GmbH...
-
Page 3: Table Of Contents
Bidirectional radio system Unidirectional radio system Principle of function 3.5.1 Mounting options 3.5.2 Schematic gure Protero-868 3.5.3 Teaching the Protero-868 to a receiver with a taught-in manual or wall transmitter 3.5.4 Deleting the programmed Protero-868 3.5.5 Threshold values 3.5.6 Setting wind sensitivity 3.5.7 Waiting time after alarm... - Page 4 Cleaning and maintaining the device EC declaration of conformity Troubleshooting Repair Manufacturer's address Disposal Legal Notes 4 | EN elero GmbH...
-
Page 5: General Information
All activities on and with this device may only be performed as they are explained in these Operating Instructions. Please store this document for the Protero-868 for later use. If you pass the device on to someone else, please hand them these Operating Instructions as well. -
Page 6: Standards And Directives
EC Declaration of Conformity which also con rms the safety herein. Intended use The device is a battery-operated, wireless vibration sensor for retractable arm awnings. The Protero-868 can be operated with the following radio receivers: • Radio tubular drives SunTop-868 •... -
Page 7: Warranty And Liability
Further elds of application have to be arranged with the manufacturer, elero GmbH Antriebstechnik (see Chapter 8, Manufacturer's Address). The operator will be solely responsible for damages result- ing from improper use of the device. The manufacturer can- not be held liable for personal or material damages caused by misuse or procedural errors, and by improper operation and commissioning. -
Page 8: Safety
• Before installing the unit at the required position, check the proper function of the Protero-868 and the receiver. General safety instructions The Operating Instructions contain all safety instructions which must be observed in order to prevent dangers inher- ent to handling the device in connection with the drives and components to be controlled. -
Page 9: Product Description
Product description General information The Protero-868 recognises vibrations (e.g. caused by wind) at an awning. The wind sensitivity can be adjusted in 10 stages by a threshold switch. If the device registers that a set threshold is reached or exceeded, it will emit a signal to the awning control which retracts the awning. -
Page 10: Unidirectional Radio System
The Protero-868 may only be programmed for the receiver on the same awning. 3.5.1 Mounting options The Protero-868 is attached on the inside of the drop pro le of the retractable arm awning with the enclosed accessories from the assembly kit. -
Page 11: Schematic Gure Protero-868
Extend the awning with a taught hand-held transmitter until you can install the Protero-868 at the drop pro le. Power down the receiver (drive) during assembly of the Protero-868. Open the Protero-868 and carefully remove the upper part of the housing with the integrated PCB. - Page 12 The receiver is now in teaching mode and signals this by extending and retraction. 4. Push the button retract at the Protero-868 at once (no later than 1 second) after retraction starts. The status indicator is lit brie y. The awning stops and then contin- ues to extend.
-
Page 13: Deleting The Programmed Protero-868
1. Extend the awning all the way. 2. Now manually vibrate the drop pro le with the installed Protero-868 to a degree that is comparable to the one at which the awning is to retract. 3. Depending upon the result (too sensitive or too insen- sitive) please change the basic factory setting of the threshold switch. -
Page 14: Waiting Time After Alarm
3.5.8 Battery replacement If the extension of the awning is interrupted twice, this is a sign that the batteries are nearly empty and should be replaced soon. Wind monitoring then is no longer active. 14 | EN elero GmbH... -
Page 15: System Conversion To Unidirectional Radio Mode
Dispose of used batteries environmentally compatibly. System conversion to unidirectional radio mode Use of the Protero-868 at an awning into which the Pro- tero-868 cannot be bidirectionally taught yet: 1. Deleting the Protero-868 Push the buttons extract and retract concurrently for at least 6 seconds 2. - Page 16 The status indicator is lit brie y. The awning stops. 11. The awning can now be controlled via the hand-held transmitter. 12. Push the teaching button P at the Protero-868 for at least one second. Then the Protero-868 switches to unidirectional operation.
-
Page 17: Technical Data
15. Push the retraction button at the Protero-868 at once (no later than 1 second) after retraction starts. The status indicator is lit brie y. The awning stops and then contin- ues, stops and then extends again. 16. Push the extension button at the Protero-868 at once (no later than 1 second) after extension starts. -
Page 18: Cleaning And Maintaining The Device
• Avoid using chemical solvents or detergents since these my damage the surface and/or labels of the Protero-868. EC declaration of conformity elero GmbH hereby declares that the Protero-868 P com- plies with the basic prerequisites and the other relevant provisions of the EC directives. -
Page 19: Repair
Protero-868 Fig. 4 Troubleshooting Protero-868 Repair If you have any questions, contact your specialist dealer from whom you bought the Protero-868. Always indicate the following: Item number and name on the type plate Type of fault Previous and unusual events... -
Page 20: Disposal
Packaging Your Protero-868 is packed to protect it against transport damage. Packagings are raw materials and can by recycled or returned to the raw material cycle. Dispose electrical and electronic components...
