VarioTel 2-915
No. 282450901, 282460901,
282470901
EN
FR
ES
PT
181221301/0510 EN/FR/ES/PT
elero

Operating instructions

Please take care of the operating instructions!
Instructions d'utilisation
Veuillez conserver les présentes instructions d'utilisation !
Instrucciones de servicio
¡Por favor, conserve estas instrucciones de servicio
Instruções de serviço
Por favor conserve as instruções de serviço !

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VarioTel 2-915 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for elero VarioTel 2-915

  • Page 1: Operating Instructions

    VarioTel 2-915 elero No. 282450901, 282460901, 282470901 Operating instructions Please take care of the operating instructions! Instructions d’utilisation elero GmbH Veuillez conserver les présentes instructions d’utilisation ! Antriebstechnik Instrucciones de servicio Linsenhofer Str. 59–63 D-72660 Beuren ¡Por favor, conserve estas instrucciones de servicio Tel.: +49 (0) 7025-13-01...
  • Page 2: Table Of Contents

    Position deletion........EN-16 Delete ventilation/tilting position .
  • Page 3: Safety Instructions/Exclusion Of Liability

    • If one or more transmitters are used for controlling the elero GmbH assumes no liability for personal injuries, property system, its operating range must stay visible during damages and financial losses that arise from non-observance of operation.
  • Page 4: Scope Of Supply/Intended Use

    The hand-held transmitter may only be used for controlling roller shutters, venetian blinds and sun protection systems that are fitted with elero radio receivers. Other use, or use which goes beyond this use is not considered to be use for intended purpose.
  • Page 5: Mounting Of The Wall Bracket

    Safety instructions for radio operation Mounting of the wall bracket C A U T I O N ! N O T I C E ! The wall bracket has to be fixed so that the drill Observe the following safety instructions for radio holes don’t touch any electrical lines.
  • Page 6: Explanation Of Functions

    Explanation of functions Explanation of functions Status LED Select button (channel selection button, AUTO switching button) A radio signal is displayed by the illumination of the Status LED Up to 5 channels can be selected by pressing the Select button (LED ring around the STOP button).
  • Page 7: Programming The Transmitter

    Programming the transmitter Programming additional transmitters Programming the transmitter Programming additional transmitters P R E R E Q U I S I T E ! N O T I C E ! The receiver must be installed. If several receivers are connected to the same feed line, then all are simultaneously ready to pro- Note that the radio range to the receiver is limited gram.
  • Page 8: Venetian Blind

    Approach limit positions Intermediate positions for roller shutters/ Roller shutter/awning/venetian blind awnings/venetian blinds P R E R E Q U I S I T E ! Roller shutters Awning Venetian blind The transmitter/transmitter channel has been programmed. The end positions of the drive have been set. Pos B Intermediate Intermediate...
  • Page 9: Program Ventilation/Tilting Position

    Intermediate positions for roller shut- Delete positions ters/ awnings/venetian blinds Program ventilation/tilting position Delete intermediate position 1. Press the STOP button and also the DOWN button. P R E R E Q U I S I T E ! 2. Hold down this button combination for approx. 3 sec. The transmitter/transmitter channel has been The status LED lights up briefly.
  • Page 10: Deletion Of All Transmitters

    Battery changing/cleaning/disposal Delete transmitter/technical data Battery replacement Delete transmitter/channel 1. Press the STOP button and also the programming button P N O T I C E ! (back of unit). • Replace batteries only with identical type 2. Hold down this button combination for approx. 6 seconds until (2 x LR 06;...
  • Page 11: Notes On Troubleshooting

    – Item description – Own presumption ETSI EN 300220-3 – Type of fault – Previously occurring unusual events Beuren, 29.12.2009 elero GmbH Ulrich Seeker Antriebstechnik – CE Officer – Linsenhofer Str. 59–63 – Representative – D-72660 Beuren Please visit us on the Internet if you require a contact outside Germany.
