S-64 E v2
Four-channel H.264 video encoder

Quick Start Guide

Unpack

Note: Subject to modification. Actual product and accessories may differ in appearance.

Connect

© Siqura B.V. 2017
Version 1.4 (141909-1.4)
S-64 E v2 QSG (MW10)
Find additional manuals, the datasheet,
the EU Declaration of Conformity and the
latest firmware for this product at:
http://www.tkhsecurity.com/support-files

Understand front panel

/
Reset button*
*Press and hold for 10 sec. to reset to factory defaults (incl. network settings)

Access via factory-set IP address (default)

S-64 E V2
10.0.231.156
Cat 5
10.x.y.0
Video Management System
Digital I/O
RS-422/485
RS-232
/

S-64 E v2 DHCP setting activated (optional)

HDMI
10.x.y.0
NTP

Install

MC10 or MC11
Power Supply Cabinet
S620 D
IP = 10.x.y.z
Cat 5
NTP
DHCP
Video Management System
http://www.tkhsecurity.com
http://www.tkhsecurity-usa.com
