Bakers Pride CBBQ-30S-B1 Specifications

The Ultimate Outdoor Broiler
BAKERS
CHAR BROILERS
PRIDE
Model CBBQ-60S-CP
with optional 30" in-line griddle plate
SPECIFICATIONS
The Ultimate Outdoor Char Broilers are designed for broiling, grilling,
steaming, roasting and holding all in a single piece of equipment.
CBBQ models feature 30" wide (762mm) or 60" wide (1524mm) by
24" deep (610mm) broiling areas. All models come standard with an
all stainless steel exterior, an 8" deep (203mm) stainless steel work
deck, stainless steel valve panel, stainless steel water/grease pans,
heavy-duty nickel-chrome plated removable top grates.
Built-in models come with front removable water/grease pans and
roll-top hood(s).
Base models come with stainless steel stand, legs, casters (two
with locks) and side-mounted tank bracket(s) to accommodate
20 lb. L.P. tanks.
Packages also include mobile tank caddy and 40 lb. L.P. tank(s).
Complete Packages also include the customer's choice of roll-top
hood(s) or wind & splash guard(s).
20,000 BTUH steel burners are located every 7" (178mm) for
maximum top heat intensity and greater production with
independently controlled, adjustable burner valves for precision
control and energy efficiency.
Standard crossover pilot tube system provides additional safety,
energy savings and ease of operation.
Exteriors are fabricated of heavy gauge type 430 stainless steel
with a #4 finish. Interiors are fabricated of 18-gauge high-heat
resistant aluminized steel. Overall exterior dimensions are 33 1/2"
deep (826mm) and either 32" (813mm) or 62 1/2" (1588mm) wide.
Height is 36" (915mm) overall including stand, legs and casters.
One (1) year limited parts and labor warranty included.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
BAKERS
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
PRIDE
www.bakerspride.com
OUTDOOR
Job ____________
GAS CHAR BROILERS
BUILT-IN MODELS
CBBQ-30S-BI
CBBQ-60S-BI
PACKAGES
CBBQ-30S-P
CBBQ-60S-P
STANDARD FEATURES
20,000 BTUH steel burners every 7" (178mm) with
q
independently controlled, adjustable valves for each burner
Up to 160,000 BTUH per broiler in natural or LP gas
q
Crossover pilot tube system
q
Stainless steel radiant heat defectors
q
Heavy-duty nickel-chrome plated top grates
q
Stainless steel, front-mounted work deck 8" deep (203mm)
q
Stainless steel valve panel
q
Stainless steel outer construction
q
Stainless steel water / grease pans
q
Pressure regulator(s)
q
Stainless steel stand
q
Set of 4 heavy duty stainless steel legs with casters two
q
with locks
Limited one year part & labor warranty
q
OPTIONS & ACCESSORIES
Smoke & Roast roll-top hoods in 30" (762mm) or 60"
q
(1524mm) sizes
Wind & Splash guards in 30" (762mm)
q
Steamer System 15" wide (381mm)
q
Full size pan set with lid
q
1/2 Size pan set with lids
q
Side mounted work deck / service shelf
q
Rear mounted work deck / service shelf
q
Stainless steel undershelves
q
Ritchlite cutting boards in 30" (762mm) or 60" (1524mm)
q
sizes for front-mounted work decks
11" Wide (279mm) removable griddle plate
q
30" Wide (762mm) In-Line griddle plate
q
All weather covers
q
Propane tank caddies
q
20 lb. or 40 lb. LP tanks with hoses
q
Built-in version
q
CERTIFICATIONS
U L
®
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
Item # ___________
G
BASE MODELS
CBBQ-30S
CBBQ-60S
COMPLETE PACKAGES
CBBQ-30S-CP
CBBQ-60S-CP
U L
C
®
®
