ECS Tuning Ziza ES2580244 Installation Procedures Manual

Interior lighting package for audi a3 2005; audi a3 2006; audi a3 2007; audi a3 2008; audi a3 2009; audi a3 2009; audi a3 2010; audi a3 2011; audi a3 2012; audi a3 2013
Hide thumbs

Advertisement

Quick Links

Download this manual
R
Ziza® Interior Lighting Package Installation Procedures
ES2580244
Part Number
for Audi A3
(2005+)
This tutorial is provided as a courtesy by ECS Tuning.
Proper service and repair procedures are vital to the safe, reliable operation of all motor vehicles as well as the personal safety
of those performing the repairs. Standard safety procedures and precautions (including use of safety goggles and proper tools
and equipment) should be followed at all times to eliminate the possibility of personal injury or improper service which could
damage the vehicle or compromise its safety.
Although this material has been prepared with the intent to provide reliable information, no warranty (express or implied) is
made as to its accuracy or completeness. Neither is any liability assumed for loss or damage resulting from reliance on this mate-
rial. SPECIFICALLY, NO WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER WARRANTY IS
MADE OR TO BE IMPLIED WITH RESPECT TO THIS MATERIAL. In no event will ECS Tuning, Incorporated or its affiliates be liable for
any damages, direct or indirect, consequential or compensatory, arising out of the use of this material.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ziza ES2580244 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ECS Tuning Ziza ES2580244

Summary of Contents for ECS Tuning Ziza ES2580244

  • Page 1 SPECIFICALLY, NO WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER WARRANTY IS MADE OR TO BE IMPLIED WITH RESPECT TO THIS MATERIAL. In no event will ECS Tuning, Incorporated or its affiliates be liable for any damages, direct or indirect, consequential or compensatory, arising out of the use of this material.

  • Page 2: Kit Contents

    42mm white LED festoon (qty 2) This tutorial explains how to install the LEDs in your Ziza Interior Lighting Kit. Make the job easier and prevent damage to headliners and other interior trim with ECS Tuning Trim and Molding ES2500877 ES517779.

  • Page 3: Bulb Types

    Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) What are LEDs? LEDs are Light Emitting Diodes, solid state devices that emit light when connected to electrical current. They have no moving parts or wire filaments to burn out. They emit a whiter light, run cooler, and last longer that the incandescent (filament style bulbs) we are replacing in this tutorial.

  • Page 4: General Tips

    Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) General Tips • When prying down on the assemblies to remove them, pry on the notched end of the lens. Insert the narrow tool tip between the lens plastic and any metal collar used to reinforce the lens mounting hole.
  • Page 5 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Ziza Interior Lighting Kit Locations Make____Audi_______________________________________ Model_____A3_______________________________________ Kit Part Number_____ES2580244________________________ cargo area 5-chip wedge base bulb ES2580814 rear dome 5-chip bayonet (qty 2) ES2515347 glove box 5-chip wedge base bulb ES2580814 sun visor 36mm festoon (qty 2)
  • Page 6 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Front Dome, Vanity, and Glove Box LED Installation Front Dome - Step 1 Using a trim removal tool, pry down gently on the edge of the front dome light lens. Pop the lens cover free and remove it.
  • Page 7 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Front Dome - Step 3 Replace the original glass festoon bulbs with 42mm festoon LED arrays (arrows). The LED arrays are polarity sensitive. If either does not work when initially installed and tested, flip it end-for-end to get it working.
  • Page 8 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Front Dome - Step 6 Install the front bayonet style LEDs. This photo (shot from the front of the dome light console looking toward the rear) shows all four LEDs installed in the front dome light console. Front Dome - Step 7 Snap the front trim piece and lens in place.
  • Page 9 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Vanity Light - Step 1 The vanity mirror lights are located in the headliner above the sun visors. Insert the tip of the trim removal tool at the notched end of the light. Press in to compress the spring clip as you pry down.

  • Page 10: Glove Box

    Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Glove Box Pry at the notched end of the glove box light to remove it. Pry the black plastic heat shield from the back of the light and replace the original wedge base glass bulb with a 5-chip wedge base LED.
  • Page 11 Ziza Interior Lighting Package Installation ES2580244 Fits Audi A3 (2005+) Rear Dome - Step 2 Note the location of the metal spring clips (arrows). Press at these locations with the trim tool tip to compress the clips as you pry down the light. The rear dome assembly has two bayonet base bulb holders.
  • Page 12 Ziza Interior Lighting Package Installation ES2580244 This concludes the installation of the Ziza Interior Light Kit. Make the job easier and prevent damage to headliners and other interior trim with ECS Tuning Trim and Molding ES2500877 ES517779. Removal Tool Sets:...
