R
Ziza® Interior Lighting Package Installation Procedures
ES2538942
Part Number
for VW CC
This tutorial is provided as a courtesy by ECS Tuning.
Proper service and repair procedures are vital to the safe, reliable operation of all motor vehicles as well as the personal safety
of those performing the repairs. Standard safety procedures and precautions (including use of safety goggles and proper tools
and equipment) should be followed at all times to eliminate the possibility of personal injury or improper service which could
damage the vehicle or compromise its safety.
Although this material has been prepared with the intent to provide reliable information, no warranty (express or implied) is
made as to its accuracy or completeness. Neither is any liability assumed for loss or damage resulting from reliance on this mate-
rial. SPECIFICALLY, NO WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER WARRANTY IS
MADE OR TO BE IMPLIED WITH RESPECT TO THIS MATERIAL. In no event will ECS Tuning, Incorporated or its affiliates be liable for
any damages, direct or indirect, consequential or compensatory, arising out of the use of this material.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ECS Tuning Ziza ES2538942
Summary of Contents for ECS Tuning Ziza ES2538942
- Page 1 SPECIFICALLY, NO WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER WARRANTY IS MADE OR TO BE IMPLIED WITH RESPECT TO THIS MATERIAL. In no event will ECS Tuning, Incorporated or its affiliates be liable for any damages, direct or indirect, consequential or compensatory, arising out of the use of this material.
-
Page 2: Kit Contents
5-chip wedge base white LED (qty 6) This tutorial explains how to install the LEDs in your Ziza Interior Lighting Kit. Make the job easier and prevent damage to headliners and other interior trim with ECS Tuning Trim and Molding ES2500877 ES517779. - Page 3 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC What are LEDs? LEDs are Light Emitting Diodes, solid state devices that emit light when connected to electrical current. They have no moving parts or wire filaments to burn out. They emit a whiter light, run cooler, and last longer that the incandescent (filament style bulbs) we are replacing in this tutorial.
- Page 4 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Ziza Interior Lighting Kit Locations Make____VW______________________________________________ Model___CC______________________________________________ Kit Part Number_____ES2538942____________________________________ trunk 42mm festoon ES2515360 rear dome 5-chip wedge (qty 3) ES2526289 glove box 5-chip wedge ES2526289 sun visor (qty 2) 36mm festoon ES2515359 front dome 5-chip wedge (qty 2)
- Page 5 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC General Tips • When prying down on the assemblies to remove them, pry on the notched end of the lens. Insert the narrow tool tip between the lens plastic and any metal collar used to reinforce the lens mounting hole.
- Page 6 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Front Dome and Vanity LED Installation Front Dome - Step 1 The front dome light console is secured in the headliner by plastic tabs and two Torx® head screws. To access the screws, use a non-marring trim re- moval tool to pry down the rear console cover.
- Page 7 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Front Dome - Step 3 The front dome light has two wedge style bulb holder sockets (arrows). Front Dome - Step 4 Twist and pull each bulb holder to remove it from its socket.
- Page 8 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Vanity Mirror Lights - Step 1 Using a non-marring trim removal tool, pry down on the light assembly as shown to release it from the headliner. Vanity Mirror Lights - Step 2 Replace the original filament bulb with a 36mm fes- toon array.
- Page 9 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Glove Box - Step 2 Replace the original filament bulb with a new 5-chip wedge base LED array. Reinstall the heat shield and replace the light assembly in the glove box. Trunk Step 1 Use the trim removal tool to pry the light assembly from the trunk.
- Page 10 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Rear Dome LED Installation Rear Dome - Step 1 Using a trim removal tool or your fingers, carefully pry or pull downward on the light assembly trim bezel, and remove it. Rear Dome - Step 2 The rear dome light assembly has three wedge base sockets.
- Page 11 Ziza Interior Lighting Package Installation ES2538942 Fits VW CC Make the job easier and prevent damage to headliners and other interior trim with ECS Tuning Trim and Molding ES2500877 ES517779. Removal Tool Sets: This concludes the installation of the Ziza Interior Light Kit.
