Normal Mode Test
After completing the above calibration procedures, you must perform a normal mode test. A current generator
capable of generating 20 mA must be connected to the COMMON and CURRENT INPUT jacks, see Figure 2.2
on page 4 (14). The
DISPLAY SELECT
1. Set the Condec Calibration Module to the NORMAL MODE position.
2.
DISPLAY SELECT
3.9
Self-Check Test
1. Remove the Condec Calibration Module.
2. Press the
pushbutton (12) on the UPC5200/UPC5210 until the unit shows
ZERO
100
to verify the unit's accuracy, then it returns to the normal mode automatically.
3. The pneumatic portion of the calibration is now complete. The pressure standard and the Condec
Calibration Module can now be disconnected.
switch (16) should be on the CURRENT position.
switch should be in the CURRENT position. The display reads
20.000
.
. The display shows
CAL
Calibration
13
