Toa BS-61WA Instruction Manual

BI-DIRECTIONAL BOX SPEAKERS
The BS-61WA and BS-61WT-A, each of which cabinet is made of wood, can be installed easily on the wall with help of the
plug-in speaker receptacle.

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read
all the instructions in this section for correct and
safe operation.
• Be sure to follow all the precautionary instructions
in this section, which contain important warnings
and/or cautions regarding safety.
• After reading, keep this manual handy for future
reference.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
• Install the unit only in a location that can
structurally support the weight of the unit and the
mounting bracket. Doing otherwise may result in
the unit falling down and causing personal injury
and/or property damage.
• Do not use other methods than specified to mount
the bracket. Extreme force is applied to the unit

2. SPECIFICATIONS

Model Number
Input
Input Impedance
Frequency Response
Sound Pressure Level
Coverage Angle
Speaker Component
Volume Control
Finish
Dimensions
Weight
Accessories
Optional Products
Note: The design and specifications are subject to change without notice for improvement.
BS-61WA
16 cm (6") cone-type speaker, 2 pcs.
200 (w) x 290 (h) x 220 (d) mm
(7.87" x 11.42" x 8.66")
2.8 kg (6.17 lb)
Machine screw M4 x 35 ... 2, Tapping screw 4 x 35 ... 2, Speaker receptacle ... 1
Suspension Bracket: YS-31W
INSTRUCTION MANUAL
BS-61WA, BS-61WT-A
and the unit could fall off, possibly resulting in
personal injuries.
• Tighten each nut and bolt securely. Ensure that the
bracket has no loose joints after installation to
prevent accidents that could result in personal
injury.
• Use the specified In-wall electrical box in
combination. Doing otherwise may cause the unit
or component to fall off, resulting in personal injury.
CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
• Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
• Do not stand or sit on, nor hang down from the unit
as this may cause it to fall down or drop, resulting
in personal injury and/or property damage.
6 W
1.7 kΩ (6 W), 5 kΩ (2 W)
130 – 13,000 Hz
92 dB (1 W, 1 m)
100º
0 (Off), 1 (Low), 2 (Middle), 3 (High)
Enclosure: Wood, off-white
Grille: Cloth, off-white
200 (w) x 292 (h) x 220 (d) mm
(7.87" x 11.50" x 8.66")
BS-61WT-A
2.9 kg (6.39 lb)
