STEP 4
Attach another two Panel (E) to assembled unit in
Step 3 using Self-Tapping Screw (1), as shown.
C
STEP 5
Insert assembled drawer in Step 1 to the unit, as shown.
Recommended Maximum Weight
10
15
15
*Unit in Pound(lbs)
A
A
B
E
E
(1)x 8pcs
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm. 1 Person
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Pasir Desk Storage Shelf w/Bin
12247
MODEL
:
DIMENSION :
23.6"(W) x 9.9"(H) x 8.3"(D)
1224720150921
