HTC 10 Verizon Manual

Meet your
About your phone
phone.
Notification light
microSD
card slot
Back
Para la versión en español, visite
verizonwireless.com/support
NOTE: Devices and software are constantly
evolving—the screen images and icons you
see here are for reference only.
HTC UltraSelfie
™ Headset jack
Earpiece camera with OIS
HTC UltraPixel ®
SIM card slot main camera
with OIS
Volume
Power/
Lock
Recent
apps
Home/Fingerprint scanner USB Type-C/charger port
HTC BoomSound
Hi-Fi edition speakers
Setting up your phone
Your phone comes with the SIM card
pre-installed.
Charge your phone
LED flash Before turning on your phone, charge
it fully.
1. Insert the small end of the USB cable
into the USB connector.
Laser
autofocus
sensor
2. Insert the other end into the power
adapter, and then plug the power
adapter into an electrical outlet.
®
WARNING: Only use approved chargers with
your device. Incompatible chargers or tampering
with the charger port could damage your device
and void the warranty.
Optional: Insert the microSD card
1. With the phone facing down, push the
tray eject pin that came with your
phone into the small hole next to the
microSD ™ card tray slot until the card
tray pops out.
2. Pull out the microSD card tray and
place the microSD card into the tray
with the gold contacts facing up.
3. Insert the tray back into the slot.
NOTE: The microSD card is sold separately. © 2016 Verizon Wireless. All Rights Reserved.
91H02905-00M Rev.A
QSG6545VW
