- Page 1 Smart Control Kit Installation Guide Installation requires no special tools—you’ll just need a screwdriver, stepladder and smartphone! Model V2 adhguardianusa.com 1-424-272-6998...
- Page 2 Thank you for purchasing the beam Smart Control Kit! Please read and follow all installation instructions. Homeowners should retain this guide for reference. TIP: If you are a professional installer, setup within the beam Home app should be done using the homeowner’s smartphone. ______________________ Date Installed: Controller...
- Page 3 Download the app & begin setup • While inside your home, download the “beam Home” from the App Store (iOS) or Google Play (Android). • Open the app, and select “Setup Your beam.” • Follow prompts within the app to enter your WiFi network name and network password.
-
Page 4: Power Up The Controller
Power up the controller • Locate the controller and power adapter . Plug the adapter into the DC IN port on the controller and a nearby power source. • The controller’s WiFi status light will blink orange to indicate it’s ready for setup. -
Page 5: Program The Controller
Program the controller • Follow prompts within the app, and when directed, press your phone screen tightly against the bottom setup port. TIP: It may be helpful to dim the lights or cup your hand over your phone during programming to minimize light interference. •... - Page 6 Scan the wireless door sensor code • Locate the wireless door sensor and follow prompts within the app to scan the code (found on the back of the sensor). • Enter a name to identify your door. • Unplug the controller and head out to the garage!
- Page 7 Mount the wireless door sensor • Clean and wipe dry an area at the top of your garage door’s interior panel. • Remove the battery tab from the back of the wireless door sensor and mount to the cleaned area of the garage door using the adhesive Velcro strip.
-
Page 8: Mount The Controller
Mount the controller • Locate the controller and power adapter , and grab your stepladder. • Clean and wipe dry your selected mounting location, either on the garage door opener or a nearby surface. Mount using the adhesive strip on the back of the controller. TIP: The controller should be mounted within 6 feet of the garage door opener and a power source. - Page 9 Connect the opener cable to the controller • Locate the opener cable • Plug the black connector into the opener port on the top of the controller. Power Indicator Opener Port DC IN Port WiFi Status...
- Page 10 Using your screwdriver, connect the other end of the opener cable to your garage door opener push button terminals. TIP: View sample connection diagrams for other garage door opener makes and models at: adhguardianusa.com/beam Sample diagram of Guardian terminals PUSH BUTTON...
- Page 11 Power up the controller & opener • Plug the power adapter into the DC IN port on the controller and a nearby power source. • Plug your garage door opener back in. All done!
- Page 12 • Do not use this device on garage door openers made before 1993 without a working photo-eye safety system. ©2018, ADH Guardian USA LLC. Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Guardian Access & Door Hardware...
