Summary of Contents for SKF TKSA 71
- Page 1 SKF Shaft Alignment Tool TKSA 71 Quick Start Guide 1. Description 1. Measuring unit S 5. Laser pitch 2. Connection blue LED 6. Power button 3. Charging red LED 7. Measuring unit M 4. Power on green LED 8. Serial number...
- Page 2 • Devices with minimum Android 4.4.2: Samsung Galaxy Tab Active, Galaxy Tab 4.0, Galaxy S4 3. Installing the apps The SKF Shaft Alignment Tool TKSA 71 is available with multiple apps. Note: These apps are pre-installed and ready to use on the SKF TKSA DISPLAY device.
- Page 3 Help section of the apps and SKF.com/Alignment b. Technical support SKF Technical Support website link is available in the help section the apps. Please visit www.skf.com/cm/tsg to find help or file a support request. SKF TKSA 71...
- Page 4 Videos Short instructional videos are available in the help section of the apps. More videos can be found on SKF Maintenance Products YouTube page: www.mapro.skf.com/youtube 6. Mounting the measuring units Mount the Measuring unit M on the Moveable machine.
- Page 5 Safety recommendations • The complete instructions for use are available on SKF.com and within the SKF TKSA 71 app. • Read and follow all warnings in this document before handling and operating the equipment. You can be seriously injured, equipment and data can be damaged if you do not follow the safety warnings.
- Page 6 Sébastien David Manager Product Development and Quality SKF Maintenance Products ® SKF is a registered trademark of the SKF Group. © SKF Group 2016/07 www.mapro.skf.com • www.skf.com/mount • MP5462 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted.
