luxCONTROL
Product manual DALI MSensor 02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DALI MSensor 02 and is the answer not in the manual?

Questions and answers

Related Manuals for Tridonic DALI MSensor 02

Summary of Contents for Tridonic DALI MSensor 02

  • Page 1 Product manual DALI MSensor 02...

  • Page 3: Table Of Contents

    &nbsp Table of contents Table of contents Scope of documentation ............. . 4 Safety instructions .

  • Page 4: Scope Of Documentation

    DALI MSensor 02 will result in incorrect operation. Please make sure you are using an up-to-date version of the masterCONFIGURATOR software. TRIDONIC GmbH & Co KG is constantly striving to develop all its products. This means that there may be changes in form, equipment and technology.

  • Page 5: Safety Instructions

    &nbsp Safety instructions Safety instructions The instructions in this section have been compiled to ensure that operators and users of the DALI MSensor 02 from Tridonic are able to detect potential risks in good time and take the necessary preventative measures.

  • Page 6: New Features

    Reaction of DALI MSensor 02 to scene recalls The way that the DALI MSensor 02 responds to scene recalls can be set. For example, it is possible to activate light control by the DALI MSensor 02 by calling up a scene ( see chapter "Special DALI settings", page 25...

  • Page 7: Introduction

    Introduction The DALI MSensor 02 is used in the comfortDIM system in Direct master mode. In this mode the sensor controls a DALI group directly. Besides Direct master mode, the DALI MSensor 02 also supports two further modes for use in combination...

  • Page 8: Description

    &nbsp Description Description The DALI MSensor 02 is a digital controller in the comfortDIM product range that can be used to control the control gear of a DALI group collectively. The sensor combines three functions in one control device: Constant light control...

  • Page 9: Installation

    Installation The DALI MSensor 02 is connected directly to the DALI circuit and does not require its own power supply. It can be connected to the DALI circuit without bothering about polarity. Power is supplied via the DALI circuit. The sensor draws 6 mA.

  • Page 10: Commissioning And Settings

    Group assignment by using rotary switch The effective range of the DALI MSensor 02 is set using the rotary switch at the rear of the sensor. All control gear located within the previously set effective range is controlled by the sensor.
  • Page 11 Replacing a faulty DALI MSensor (V1.5 or earlier) It is only possible to replace a faulty DALI MSensor (V1.5 or earlier) by a DALI MSensor 02 if specific preconditions are met: Make sure that there is no other DALI MSensor (V1.5 or earlier) in the DALI group in question! Make sure that the faulty DALI MSensor (V1.5 or earlier) is not influenced by other DALI controllers (e.g.

  • Page 12: Functions

    DALI MSensor 02. This also applies in cases where motion is detected in the room. The luminaire group is switched on again as soon as the measured illuminance falls below the brightness setpoint.
  • Page 13 Light control of the luminaire group is activated by triggering the DALI MSensor 02. Ambient light control: "enabled" The light control of the DALI MSensor 02 is permanently deactivated. A fixed setpoint in the luminaire Ambient light group is invoked by triggering the DALI MSensor 02. control: "disabled"...
  • Page 14 Set the desired brightness by pressing the Up/Down button (F and G) Save the new brightness setpoint by pressing the SET button (C) -› DALI MSensor 02 briefly dims the luminaire group up and down Procedure with DALI-RC For the names of the buttons with letters, see the figure showing the DALI RC ( see chapter "DALI RC", page 22...
  • Page 15 Position the sensor so that it is not directly exposed to other artificial light sources (e.g. free-standing luminaires in the room). Documentation DALI MSensor 02 | 02-2012 | en - 15 / 38 -...
  • Page 16 Overlapping detection areas may cause the different control circuits to affect one another and this may lead to false results. Position the sensors so that their detection areas do not overlap. Documentation DALI MSensor 02 | 02-2012 | en - 16 / 38 -...

  • Page 17: Presence Control

    Notice The presence-based control of the DALI MSensor 02 reacts to moving thermal radiation from people. Other heat sources (e.g. photocopiers, radiators, etc.) may have an adverse affect on presence-based control. Make sure that there are no other heat sources in the immediate vicinity of the sensor.
  • Page 18 DALI RC). The manual switch-on command (e.g. scene recall) must either be directed at the luminaire group "enabled or to all devices (broadcast) in order for presence-based control to be activated. The DALI MSensor 02 (only OFF)" ignores switch-on commands sent to other groups.
  • Page 19 "Source directory", page 35 Enhanced functionality DALI MSensors 02 of different DALI groups can synchronise their motion detection, i.e. a DALI MSensor 02 can monitor other DALI groups with DALI MSensors 02 and respond appropriately to the "Motion detected" synchronisation command in another group.
  • Page 20 In the operating mode: "enabled (only OFF)", the DALI MSensor 02 does not respond to synchronisation commands until the sensor has been activated by a manual switch-on command.

  • Page 21: Remote Control

    &nbsp Remote control Remote control Description The DALI MSensor 02 can be operated with two remote controls: IR SMART Controller DALI RC IR SMART Controller The IR SMART Controller is used to operate the assigned luminaire group in the DALI system. This remote control offers the...
  • Page 22 K AUTOMATIC control mode ON E Light value 25 % brightness Call up scene 2 Light value 12 % brightness H Call up scene 1 G Light value 6 % brightness Documentation DALI MSensor 02 | 02-2012 | en - 22 / 38 -...
  • Page 23 Setting the effective range (group assignment) IR SMART Controller The effective range of the IR SMART Controller is the luminaire group that is set on the DALI MSensor 02. This setting is made via the DALI MSensor 02 ( see chapter "Commissioning and settings", page 10...
  • Page 24 If the masterCONFIGURATOR software is used to customise the button assignments, the rotary switch in the battery compartment of the remote control is disabled. The commands will then only apply to the luminaire group selected on the DALI MSensor 02. Documentation DALI MSensor 02 | 02-2012 | en - 24 / 38 -...

  • Page 25: Special Dali Settings

    When used in combination with other manufacturers' controllers: please check compatibility! The DALI MSensor 02 is designed so that it can be combined with other DALI controllers. This is why the sensor responds to some DALI commands in a different way than that specified in the official DALI standard. This ensures that other DALI controllers, e.g.
  • Page 26 In switched-off state: presence detector is activated and changes to "Presence" state. In switched-on state: presence detector changes to "Presence" state, delay time is restarted. Constant light control: static Light control is temporarily deactivated Documentation DALI MSensor 02 | 02-2012 | en - 26 / 38 -...
  • Page 27 Implementation of DALI commands in other comfortDIM controllers If the DALI MSensor 02 is combined with other comfortDIM controllers in a DALI circuit, its behaviour can be influenced by the above-mentioned DALI commands. The following matrix lists those commands that are output by a particular device.
  • Page 28 Scene recalls using the DALI SC, DALI TOUCHPANEL (factory setting), x-touchBOX or x-touchPANEL are sent to all devices, this means that all DALI MSensors 02 with appropriate parametrisation respond to them! Documentation DALI MSensor 02 | 02-2012 | en - 28 / 38 -...

  • Page 29: Enhanced Functionality

    DALI master controller: Indirect master mode Slave mode Ex factory, the DALI MSensor 02 is in Direct master mode. The sensor can be switched to the desired mode by using the master controller itself or by using the masterCONFIGURATOR software. Notice...

  • Page 30: Practical Examples

    Command X: Recall scene 1 Configuration of input 2: Configuration of input 2: Target: Group 0 Target: Group 1 Function: Momentary-action switch Function: Momentary-action switch Command X: OFF Command X: OFF Documentation DALI MSensor 02 | 02-2012 | en - 30 / 38 -...

  • Page 31: Corridor

    If there are multiple DALI MSensors 02 in a group, light control behaves as follows: the light value is raised until it is no longer less than the setpoint value at any of the sensors. Documentation DALI MSensor 02 | 02-2012 | en - 31 / 38 -...

  • Page 32: Neighbourhood Function

    Group 6 (switch position 1) (switch position 2) (switch position 7) Configuration Reaction to presence in other groups: Group: 0 and 1 Function: Go to Absence value Documentation DALI MSensor 02 | 02-2012 | en - 32 / 38 -...

  • Page 33: Disposal

    &nbsp Disposal Disposal For disposal in accordance with the WEEE Directive: Return the device to Tridonic or dispose of the device in accordance with national regulations. Do not dispose of the device in nonrecyclable waste. Do not burn the device.

  • Page 34: Compliance

    EN 55015 (Limit values and measuring procedures for radio interference) EN 61547 (EMC requirements) With the CE symbol on its products and with the compliance declaration, Tridonic confirms that its products comply with EMC standards. Documentation DALI MSensor 02 | 02-2012 | en...

  • Page 35: Reference List

    Tridonic software: http://www.tridonic.com/com/en/software.asp Download masterCONFIGURATOR: http://www.tridonic.com/com/en/software-masterconfigurator.asp Additional information DALI manual: http://www.tridonic.com/com/en/download/technical/DALI-manual_en.pdf Guarantee conditions: http://www.tridonic.com/com/en/guarantee.asp Data sheets: http://www.tridonic.com/com/en/data-sheets.asp Environmental declarations: http://www.tridonic.com/com/en/environmental-declarations.asp Product specifications: http://www.tridonic.com/com/en/product-specifications.asp Other technical documents: http://www.tridonic.com/com/en/technical-docs.asp Documentation DALI MSensor 02 | 02-2012 | en - 35 / 38 -...

  • Page 36: Appendix

    => Lighting control temporarily disabled (static operation) operation) Calling up Scene 15 Calling up Scene 15 => Lighting control is enabled (automatic => Lighting control is enabled (automatic operation) operation) Documentation DALI MSensor 02 | 02-2012 | en - 36 / 38 -...

  • Page 37: Commands To Dali Address

    Commands to DALI address The following table lists those commands that are supported by the DALI MSensor 02 and are sent to the DALI address. DALI commands to which the sensor reacts in a different way than specified in the DALI standard are explained.
  • Page 38 DALI "RECALL MAX LEVEL" and "RECALL MIN LEVEL" commands When the "RECALL MAX LEVEL" command is sent to the DALI address of the DALI MSensor 02, its internal LED starts to flash. This makes it possible to identify the sensor in the system.The "Recall Min" function complements the "Recall Max"...
