- Page 1 Tconverter product manual LCAI 2x038/0500 K013 one4all LCAI 2x050/0500 K013 one4all...
-
Page 3: Table Of Contents
Downloads ................15 Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en... -
Page 4: Chronostep Function
Two time intervals can be defined using Profile 1 (formerly U6M): Time 1 defines how many hours before Virtual Midnight the lighting is dimmed to a lower level; Time 2 defines how many hours after Virtual Midnight the dimming level is raised again. Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 4 / 15... -
Page 5: Configuration
= can be adjusted using masterCONFIGURATOR Dimming level ("Intensity 1") is grayed out in the masterCONFIGURATOR and can only be changed indirectly. For this the Power On Level must be changed. Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 5 / 15... - Page 6 2: In masterCONFIGURATOR, the parameters are set and are assigned to a scene In Programming mode 2 the predefined output currents can be selected Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 6 / 15...
-
Page 7: Optical Balancing Function
In masterCONFIGURATOR (see Reference list), the current level for each channel is set and assigned to a scene Programming mode 2 is used to assign the newly defined scene to Output Profile 2 Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 7 / 15... -
Page 8: Programming Modes
1 and 15 seconds for programming mode 2. This is used to distinguish between the two programming modes so that the chosen values can be assigned correctly. NOTICE Changes to settings are not effective immediately but are only apparent after completing the configuration. Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 8 / 15... -
Page 9: Programming
When making the settings for Time 1 or Time 2, if the On period exceeds the maximum length of 600 seconds (equivalent to 600 minutes or 10 hours), the device terminates the configuration and switches into normal operating mode. Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 9 / 15... - Page 10 An On period of 1 second equates to 1 minute for Time 1 Switch device off again (Off period: > 5 s) → device is ready for setting Time 2 Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 10 / 15...
- Page 11 Switch device off again (Off period: > 5 s) → device is ready for confirmation of configuration Block 3: Confirmation Switch device on (On period: 5 s) and switch off again → device closes the configuration Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 11 / 15...
-
Page 12: Programming Mode 2
Configuration block. This is done by mapping the length of the On cycle onto a scale of 13 presets (for the Optical Balancing function) or a scale of 6 scenes (for the chronoSTEP function). Requirement Suitable switch connected to phase to switch the device On/Off Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 12 / 15... - Page 13 500 mA 500 mA 40 s 533 mA 467 mA 45 s 567 mA 433 mA 50 s 600 mA 400 mA 55 s 633 mA 367 mA Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 13 / 15...
- Page 14 Switch device off again (Off period: > 5 s) → device is ready for confirmation of configuration Block 3: Confirmation Switch device on (On period: 15 s) and switch off again → device closes the configuration Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 14 / 15...
-
Page 15: Reference List
Related documents http://www.tridonic.com/com/en/download/technical/DALI-manual_en.pdf DALI manual: masterCONFIGURATOR documentation: http://www.tridonic.com/com/en/download/Manual_masterConfigurato r_en.pdf Data sheets: http://www.tridonic.com/com/en/data-sheets.asp Declarations of conformity: http://www.tridonic.com/com/en/declarations-of-conformity.asp Certificates: http://www.tridonic.com/com/en/certificates.asp ENEC certificate: http://www.tridonic.com/com/en/download/certificates/ENEC_IK-1549_LCAI_K013_one4all.pdf Downloads Tridonic software: http://www.tridonic.com/com/en/software.asp Download masterCONFIGURATOR: http://www.tridonic.com/com/en/software-masterconfigurator.asp Documentation LCAI 2x038/0500 K013 one4all | 08-2013 | en 15 / 15...
