Setting up / unfolding your rollator
Place the rollator in front of you in the direction of travel.
Using both hands, press the tubes on either side of the seat
down to the left and right until the locking pin A clicks into
place.
Caution! The rollator must never be used unless the locking
pin A is properly engaged.
A
CLICK!
Folding up your rollator
Release the locking pin A by pulling it slightly backwards and
pull up the seat by it´s folding strap.
The rollator will now fold up automatically.
A
Grip handle adjustment
Loosen screw B and remove it completely.
Adjust the grip handles to the height desired.
Place screw B back in it´s hole and tighten it firmly.
B
Brake adjustment
The brake is set up correctly if there is no play in either the
brake lever or the Bowden cable and if the wheels turn
without any rubbing or grating.
The braking power can be adjusted using the set screw C of the
Bowden cable on the brake blocks of the back wheels.
C
Walking with your rollator
Position yourself inside the rollator. Grab the handgrips with
both hands. As soon as you stand safely, you can loosen the
parking brakes.
- Do not push the rollator too far in front of you. In order to
give good support, the rollator should be kept close to your
body.
- Control your speed by gently applying both brakes evenly.
- Walk upright and look forwards to be able to avoid any
upcoming obstacles early. Walking backwards with your
rollator is difficult, and not recommended.
Braking
To reduce speed while walking just pull both levers evenly and
gently upwards. Always apply the same amount of power on
both brake levers.
To lock the brakes, push the levers downwards. The brake
levers will lock audibly into place. To release the brakes just
pull the lever upwards again.
CLICK!
