Dietz TAIMA M GT User Manual

USER MANUAL
INTRUDUCTION
The TAiMA rollator is exceptionally light, strong and can easily be folded
to stow away. It provides ideal support during all your daily ventures as
well a seat to rest.
Before using the rollator for the first time please read this manual care-
fully and make sure to be familiar with all features of the product.
The rollator described on this information sheet complies with
EU Directive 93/42 for medical products.
These instructions for use are an integral part of the scope of delivery.
The user should keep them available at all times and keep them with the
product if this is passed on to a third party.
The manufacturer reserves the right to make changes relative to
the information provided in these instructions as a result of technical
developments and improvements.
This document may be reprinted, translated and/or duplicated in any form
whatsoever, in part or in full, only subject to the manufacturer's prior
written consent.
There is no update service for this users manual. Please contact the
manufacturer to keep abreast of new developments.
SPECIFICATIONS AND INTENDED PURPOSE
The TAiMA rollator is intended as a walking aid for persons with impaired
mobility who weigh up to 150 kg. It also provides a limited seating
function for temporary rest.
The rollator should be used only on firm, flat surfaces. It is not intended
to be used for any other purpose – in particular as a climbing aid or to
carry heavy loads. Any such use can be dangerous!
EN CONTRAINDICATION
Use of the rollator is unsuitaible in case of
- False sensation
- Severe disequilibrium
- With a body weight above 150 kg
SAFETY INFORMATION
Do not hang bags on the handles as this could cause the rollator to tip
over.
Use the service brake (by pulling the brake lever up) on inclines.
Only use the rollator on firm, flat surfaces.
Do not lean too heavily on the handles. Otherwise, the rollator could tip
over backwards.
Be careful not to trap your fingers or clothes when folding up the rollator.
Upholstered parts become hot when exposed to direct sunlight and can
cause damage to the skin if you touch them. These parts should be cove-
red over. Alternatively, keep your rollator away from direct sunlight.
Before using your rollator, make sure the locking pin is correctly engaged
and the rollator can not fold up randomly.
Before each ride, check that the brakes are working properly and that all
bolted connections are tight.
Always lock both brakes before sitting on your rollator.
The maximum load for the shopping bag is 5 kg.
1
2
3
4
5
6
7
8
9
1. Backrest
2. Ergonomic handgrips
3. Brake lever
4. Cane holder
5. Height adjustment screw
6. Locking pin
7. Reflectors
8. Brake
9. Curb climber
DIETZ TAiMA_M_GT /_S_GT /_M_ECO User Manual I Version 2.1.1 I State 01.04.2019
