Mylaps X2 Server Quick Start Manual page 2

The MYLAPS X2 Server will always shut down when both the DC mains power supply
and the PoE+ power supply are disconnected. Power down will take a few seconds as
the MYLAPS X2 Server will close down the database using its internal 'close down'
power source. The display will show 'powering down'.
Make sure your computer is configured to obtain an IP address automatically.
Check the display to see if the MYLAPS X2 Server obtained an IP address from a DHCP
server. If this is the case, proceed to 'Start using the MYLAPS X2 Server'.
When there is no DHCP server available on the network the MYLAPS X2 Server will
obtain a 'local link' IP address itself. In this case the display will show an IP address in
the 169.254.x.x range. This will occur for example when the network port is connected
directly to a laptop via a UTP cable.
Technical Specifications of the MYLAPS X2 Server
• Dimensions
• Weight
• GPS Receiver
• GPS antenna connection
• Power consumption
• Operating temperature range -20 to 50 °C / -4 to 122 °F
• Operating voltage range
• Network interface
• Storage
• Cooling
• Internal battery
Specifications are subject to change without notice
CE information:
This device complies with the EMC directive 89/336/EEC. A copy of the declaration of
conformity can be obtained at:
MYLAPS Sports Timing
Zuiderhoutlaan 4
2012 PJ Haarlem
The Netherlands
220x180x60mm
1.8kg / 3.9lb
quick fix, -160dB, 15nS
SMA, active
max. 15W per connection
10 to 14.4 VDC, Typical 12 VDC
10-100BT (RJ45)
120 GB, Solid state
Passive
30 seconds soft power down after power loss
