Replacing Cartridges - Geyser ECO Installation And Operation Manual

Secure the faucet on the sink. Pass through the blue-color tube into nut (Е) (Fig. 1). Insert
piston (Z) inside the tube as far as it will go. Put plastic stop ring (L) onto the tube end (Fig. 2).
Screw the nut onto the threaded faucet rod (Fig. 3).
1
Е
Z
Before starting to use the filter, wash it through for 2-5 minutes. Wash the filter through after
replacing the cartridge and after a lengthy interruption in use (more than 5 days). There's air left
in the system after the installation of the new filter or after replacing the cartridge. This leads to
excessive water aeration (visually the water appears to be of milky white color). As the filter is
used, the air will leave the system and the cleaned water will become transparent.

REpLACING CARTRIDGES

Cut off the water supply to the filter. Open clear water faucet. Disconnect the tube from filter.
Loose the clamp connection (Fig. 1) open the clamp and detach the cover from the housing (Fig. 2).
Remove the cartridge (Fig. 3). Remove the plug from the bottom part of the cartridge and
put it at the new one. Install new cartridge and put it at the filter cap. Lubricate the o-ring with
silicone grease (not sealant!) or vaseline.
Insert the cartridge with the cap into the housing and latch the clamp. Screw the clamp
connections. Supply water to the filter and make sure that there is no leakage in all connections,
rectify if required. Let the water run through the filter for 2 minutes.
1
PLEASE NOTE! Tighten the collar clamp if there should be any leakage from under the
lid of the body.
2
L
2
3
3
